Panasonic 330μF Hybrid Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - EEHAZS1V331B

View all Aluminium Capacitors
Bulk discount available

Subtotal (1 tape of 2 units)*

£3.13

(exc. VAT)

£3.756

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tape*
2 - 8£1.565£3.13
10 - 48£1.10£2.20
50 - 98£0.71£1.42
100 - 248£0.69£1.38
250 +£0.615£1.23

*price indicative

Packaging Options:
Sponsored
A Panasonic surface mount resistor on a burgandy background
Panasonic Brand Logo
Panasonic Aluminium Capacitors & Surface Mount Resistors
Build reliable, compact designs with Panasonic’s trusted aluminium capacitors and precision surface mount resistors.
Shop Here
RS Stock No.:
210-5760
Mfr. Part No.:
EEHAZS1V331B
Brand:
Panasonic
Find similar products by selecting one or more attributes.
Select all

Brand

Panasonic

Capacitance

330µF

Voltage

35V dc

Mounting Type

Radial, Through Hole

Technology

Hybrid

Dimensions

10 (Dia.) x 11.7 x 0.8mm

Length

11.7mm

Diameter

10mm

Maximum Operating Temperature

+125°C

Lead Pitch

5mm

Tolerance

±20%

Automotive Standard

AEC-Q200

Series

ZS-A

Polarised

Polar

COO (Country of Origin):
JP
The Panasonic ZS series conductive polymer hybrid aluminium electrolytic capacitor has ±20 % tolerance and used 35 V voltage. It has 330μF of capacitance which size code is G12 and has and ultra low ESR between 11 mΩ and 19 mΩ.

Endurance 4000 h at 125 ℃ (Large capacitance / High ripple current / Low ESR)
Taping products for automatic insertion
AEC-Q200 compliant
