Panasonic 100μF Hybrid Hybrid Aluminum Electrolytic Capacitor 63V dc, Radial, Through Hole - EEHAZS1J101B
- RS Stock No.:
- 210-5755
- Mfr. Part No.:
- EEHAZS1J101B
- Brand:
- Panasonic
Subtotal (1 box of 500 units)*
£345.00
(exc. VAT)
£415.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,500 unit(s) shipping from 05 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
500 + | £0.69 | £345.00 |
*price indicative
- RS Stock No.:
- 210-5755
- Mfr. Part No.:
- EEHAZS1J101B
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Panasonic | |
Capacitance | 100µF | |
Voltage | 63V dc | |
Mounting Type | Radial, Through Hole | |
Technology | Hybrid | |
Dimensions | 10 (Dia.) x 11.7 x 0.8mm | |
Length | 11.7mm | |
Minimum Operating Temperature | -55°C | |
Diameter | 10mm | |
Maximum Operating Temperature | +135°C | |
Lead Pitch | 5mm | |
Series | ZS-A | |
Automotive Standard | AEC-Q200 | |
Tolerance | ±20% | |
Ripple Current | 3A | |
Leakage Current | 63 μA | |
Polarised | Polar | |
Dissipation Factor | 200% | |
Select all | ||
---|---|---|
Brand Panasonic | ||
Capacitance 100µF | ||
Voltage 63V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Hybrid | ||
Dimensions 10 (Dia.) x 11.7 x 0.8mm | ||
Length 11.7mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 10mm | ||
Maximum Operating Temperature +135°C | ||
Lead Pitch 5mm | ||
Series ZS-A | ||
Automotive Standard AEC-Q200 | ||
Tolerance ±20% | ||
Ripple Current 3A | ||
Leakage Current 63 μA | ||
Polarised Polar | ||
Dissipation Factor 200% | ||
- COO (Country of Origin):
- JP
Panasonic ZS-A Series Hybrid Aluminium Electrolytic Capacitor, 100μF Capacitance, 63V DC Voltage - EEHAZS1J101B
This hybrid aluminium electrolytic capacitor is engineered for high performance in various electronic applications. Designed by Panasonic, this component features a capacitance of 100 μF and a voltage rating of 63V DC. With a compact size of 10mm in diameter and a height of 11.7mm, it is ideal for space-constrained designs. This capacitor excels in reliability and efficiency, meeting stringent specifications for performance.
Features & Benefits
• Delivers 100 μF capacitance for effective energy storage
• Operates at a maximum voltage of 63V DC for safety
• Radial through hole mounting ensures easy integration
• AEC-Q200 compliant for automotive application reliability
• Minimal leakage current of 63μA enhances longevity
• Capable of high ripple currents up to 3000mA for robust performance
• Operates at a maximum voltage of 63V DC for safety
• Radial through hole mounting ensures easy integration
• AEC-Q200 compliant for automotive application reliability
• Minimal leakage current of 63μA enhances longevity
• Capable of high ripple currents up to 3000mA for robust performance
Applications
• Suitable for automotive electronic control systems
• Used in power supply circuits requiring efficient energy management
• Ideal for needing space-efficient capacitor designs
• Employed in high-performance audio equipment for filtering
• Used in power supply circuits requiring efficient energy management
• Ideal for needing space-efficient capacitor designs
• Employed in high-performance audio equipment for filtering
What advantages does this capacitor offer for automotive projects?
Its AEC-Q200 compliance ensures reliable performance in automotive settings, with low leakage current and high ripple current capacity, allowing it to withstand challenging conditions often found in vehicles.
How does the temperature range affect its functionality?
With an operating temperature from -55°C to +135°C, it remains functional across a wide temperature spectrum, making it suitable for diverse environments, from extreme cold to high heat.
What does the term hybrid technology signify in this capacitor?
Hybrid technology refers to a combination of metal and organic materials enhancing performance and reliability, ensuring efficient energy storage with reduced leakage and improved thermal management.
