Bulk discount available
Subtotal (1 pack of 20 units)*
£7.08
(exc. VAT)
£8.50
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 100 unit(s) ready to ship
- Plus 560 unit(s) shipping from 06 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 20 - 80 | £0.354 | £7.08 |
| 100 - 180 | £0.311 | £6.22 |
| 200 - 480 | £0.275 | £5.50 |
| 500 + | £0.219 | £4.38 |
*price indicative
- RS Stock No.:
- 181-5482
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | Capacitor | |
| Capacitance | 10μF | |
| Voltage | 450V dc | |
| Construction | Radial Can | |
| Mount Type | Radial, Through Hole | |
| Height | 20mm | |
| Length | 20mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 10mm | |
| Termination Type | Radial Lead | |
| Pin Count | 2 | |
| Capacitor Ripple Current | 120mA | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 1000 h | |
| Standards/Approvals | RoHS | |
| Lead Pitch | 5mm | |
| Series | LPS | |
| Leakage Current | 3μA | |
| Automotive Standard | No | |
| Tolerance | ±20 % | |
| Dissipation Factor | 17% | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type Capacitor | ||
Capacitance 10μF | ||
Voltage 450V dc | ||
Construction Radial Can | ||
Mount Type Radial, Through Hole | ||
Height 20mm | ||
Length 20mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 10mm | ||
Termination Type Radial Lead | ||
Pin Count 2 | ||
Capacitor Ripple Current 120mA | ||
Maximum Operating Temperature 105°C | ||
Lifetime 1000 h | ||
Standards/Approvals RoHS | ||
Lead Pitch 5mm | ||
Series LPS | ||
Leakage Current 3μA | ||
Automotive Standard No | ||
Tolerance ±20 % | ||
Dissipation Factor 17% | ||
RS PRO Electrolytic Capacitor
The RS PRO 10μF through-hole mount electrolytic capacitor has a voltage rating of 450VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 10mm x 20mm (diameter x length). This capacitor is designed with a safety vent construction.
Features and Benefits
• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 120mA
• Dissipation factor: 12%
• Lead pitch: 5mm
• Load life: 3000∼10000 hours at 150 °C
• Impedance: 4ohm
• Operating temperature ranging between -25°C and 105°C
Applications
• Used in communication equipment
• Switching power supply
• Industrial measuring instruments
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
