KEMET 330 μF Capacitor 500V dc, Snap-in - ALC80A331DF500
- RS Stock No.:
- 181-3331
- Mfr. Part No.:
- ALC80A331DF500
- Brand:
- KEMET
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 181-3331
- Mfr. Part No.:
- ALC80A331DF500
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Product Type | Capacitor | |
| Capacitance | 330μF | |
| Voltage | 500V dc | |
| Construction | Cylindrical Can | |
| Mount Type | Snap-in | |
| Packaging | Tape & Reel | |
| Polarity | Polar | |
| Length | 50mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 35mm | |
| Termination Type | Screw | |
| Pin Count | 2 | |
| Capacitor Ripple Current | 6.1A | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 30000 h | |
| Lead Pitch | 10mm | |
| Standards/Approvals | RoHS, IEC 60384-4 | |
| Series | ALC80 | |
| Tolerance | ±20 % | |
| Leakage Current | 495μA | |
| Automotive Standard | No | |
| Equivalent Series Resistance ESR | 517Ω | |
| Select all | ||
|---|---|---|
Brand KEMET | ||
Product Type Capacitor | ||
Capacitance 330μF | ||
Voltage 500V dc | ||
Construction Cylindrical Can | ||
Mount Type Snap-in | ||
Packaging Tape & Reel | ||
Polarity Polar | ||
Length 50mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 35mm | ||
Termination Type Screw | ||
Pin Count 2 | ||
Capacitor Ripple Current 6.1A | ||
Maximum Operating Temperature 105°C | ||
Lifetime 30000 h | ||
Lead Pitch 10mm | ||
Standards/Approvals RoHS, IEC 60384-4 | ||
Series ALC80 | ||
Tolerance ±20 % | ||
Leakage Current 495μA | ||
Automotive Standard No | ||
Equivalent Series Resistance ESR 517Ω | ||
The KEMET ALC80 High CV snap-in capacitors offer high performance and reliability in a wide range of case sizes and voltage ratings featuring high ripple currents and long-life performance. Volumetric efficiency ensures the maximum capacitance capability in a smaller size.
Maximum capacitance capability in a smaller size
Long life, up to 9,000 hours at +105°C (VR,IR applied)
High ripple current
Excellent surge voltage capability
Applications
Typical applications for the ALC80 capacitor includes alternative energy, smoothing, energy storage, or pulse operation in telecommunications, demanding power supplies (SMPS), process control, AC motor control, traction, welding, frequency converters, uninterruptible power supply (UPS) systems, and measuring.
