Panasonic 1000 μF Capacitor 35V dc, Radial - EEUFP1V102B Radial Lead

This capacitor is a premium Aluminium Electrolytic component designed to provide high performance in diverse applications. With a capacitance of 1000μF and a voltage rating of 35 V DC, it features a radial through-hole mounting type that simplifies integration into electronic circuits. The Compact dimensions of 12.5mm in diameter and 20mm in height make it suitable for space-constrained environments, while its operating temperature range of -55°C to +105°C ensures reliability in various conditions.

• Exceptional capacitance of 1000μF ensures stable power supply
• Rated for 35 V DC to handle high voltage applications
• Low equivalent series resistance of 38 mΩ enhances efficiency
• Polarised design supports optimal circuit functionality
• High ripple current capacity of 3250 mArms for demanding loads
• Suitable for automotive applications with AEC-Q200 compliance

• Used in power supplies for automotive electronics
• Suitable for filtering in audio systems
• Effective in timing circuits in various electronic devices
• Utilised in motor control circuits for industrial machinery

The AEC-Q200 compliance indicates that it meets stringent automotive standards, ensuring durability and reliability under varying temperatures and vibration conditions, which are common in vehicular environments.

The capacitance Value of 1000μF allows for effective energy storage and smoothing of voltage fluctuations, making it Ideal for stabilising power supply in high-load circuits.

The operational temperature range of -55°C to +105°C allows this component to function efficiently in extreme conditions, providing versatility in design and application.

A low ESR of 38 mΩ minimises energy loss during operation, enhancing overall efficiency and helping to prolong the life of both the capacitor and the circuit it supports.
