Panasonic 150μF Aluminium Electrolytic Capacitor 100V dc, Radial, Through Hole - EEUFS2A151B
- RS Stock No.:
- 176-3924
- Mfr. Part No.:
- EEUFS2A151B
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 pack of 10 units)*
£7.54
(exc. VAT)
£9.05
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 90 | £0.754 | £7.54 |
| 100 - 240 | £0.701 | £7.01 |
| 250 - 490 | £0.642 | £6.42 |
| 500 - 990 | £0.596 | £5.96 |
| 1000 + | £0.542 | £5.42 |
*price indicative
- RS Stock No.:
- 176-3924
- Mfr. Part No.:
- EEUFS2A151B
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 150µF | |
| Voltage | 100V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 12.5 Dia. x 20mm | |
| Height | 20mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 12.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 10000h | |
| Lead Pitch | 5mm | |
| Polarised | Polar | |
| Leakage Current | 0.01 CV (After 2 Minutes) μA | |
| Tolerance | ±20% | |
| Ripple Current | 1.4A | |
| Series | FS | |
| Dissipation Factor | 0.08% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 150µF | ||
Voltage 100V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 12.5 Dia. x 20mm | ||
Height 20mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 12.5mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 10000h | ||
Lead Pitch 5mm | ||
Polarised Polar | ||
Leakage Current 0.01 CV (After 2 Minutes) μA | ||
Tolerance ±20% | ||
Ripple Current 1.4A | ||
Series FS | ||
Dissipation Factor 0.08% | ||
