Panasonic 270μF Aluminium Electrolytic Capacitor 80V dc, Radial, Through Hole - EEUFS1K271L
- RS Stock No.:
- 176-3868
- Mfr. Part No.:
- EEUFS1K271L
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 pack of 10 units)*
£4.27
(exc. VAT)
£5.12
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 10 | £0.427 | £4.27 |
| 20 - 40 | £0.384 | £3.84 |
| 50 - 90 | £0.328 | £3.28 |
| 100 + | £0.311 | £3.11 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 10)
£0.67
(exc. VAT)
£0.80
(inc. VAT)
- RS Stock No.:
- 176-3868
- Mfr. Part No.:
- EEUFS1K271L
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 270µF | |
| Voltage | 80V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10 (Dia.) x 25mm | |
| Height | 25mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 10mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 10000h | |
| Lead Pitch | 5mm | |
| Leakage Current | 0.01 CV (After 2 Minutes) μA | |
| Ripple Current | 1.2A | |
| Polarised | Polar | |
| Tolerance | ±20% | |
| Series | FS | |
| Dissipation Factor | 0.08% | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Capacitance 270µF | ||
Voltage 80V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 10 (Dia.) x 25mm | ||
Height 25mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 10mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 10000h | ||
Lead Pitch 5mm | ||
Leakage Current 0.01 CV (After 2 Minutes) μA | ||
Ripple Current 1.2A | ||
Polarised Polar | ||
Tolerance ±20% | ||
Series FS | ||
Dissipation Factor 0.08% | ||
