Panasonic 330μF Aluminium Electrolytic Capacitor 100V dc, Radial, Through Hole - EEUFS2A331L
- RS Stock No.:
- 176-3830
- Mfr. Part No.:
- EEUFS2A331L
- Brand:
- Panasonic
Available to back order for despatch 10/06/2024
Added
Price Each (In a Bag of 100)
£0.869
(exc. VAT)
£1.043
(inc. VAT)
| Units | Per unit | Per Bag* |
| 100 - 200 | £0.869 | £86.90 |
| 300 + | £0.806 | £80.60 |
| *price indicative | ||
- RS Stock No.:
- 176-3830
- Mfr. Part No.:
- EEUFS2A331L
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
Low ESR, Miniaturized (1 size smaller than series FR)
Endurance : 105 °C 5000 h to 10000 h
Endurance : 105 °C 5000 h to 10000 h
Specifications
Attribute | Value |
|---|---|
| Capacitance | 330µF |
| Voltage | 100V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 12.5 Dia. x 35mm |
| Height | 35mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 10000h |
| Tolerance | ±20% |
| Series | FS |
| Polarised | Polar |
| Leakage Current | 0.01 CV (After 2 Minutes) μA |
| Ripple Current | 2.38A |
| Dissipation Factor | 0.08% |
