Panasonic 390μF Aluminium Electrolytic Capacitor 80V dc, Radial, Through Hole - EEUFS1K391B
- RS Stock No.:
- 176-3796
- Mfr. Part No.:
- EEUFS1K391B
- Brand:
- Panasonic
Sorry, we couldn't check our stock levels right now. Please try refreshing the page.
Not available for guaranteed pre 9am/10am delivery
Added
Price Each (In a Bag of 500)
£0.901
(exc. VAT)
£1.081
(inc. VAT)
| Units | Per unit | Per Bag* |
| 500 - 500 | £0.901 | £450.50 |
| 1000 - 1500 | £0.869 | £434.50 |
| 2000 - 2500 | £0.82 | £410.00 |
| 3000 - 4500 | £0.773 | £386.50 |
| 5000 + | £0.753 | £376.50 |
| *price indicative | ||
- RS Stock No.:
- 176-3796
- Mfr. Part No.:
- EEUFS1K391B
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
Low ESR, Miniaturized (1 size smaller than series FR)
Endurance : 105 °C 5000 h to 10000 h
Endurance : 105 °C 5000 h to 10000 h
Specifications
Attribute | Value |
|---|---|
| Capacitance | 390µF |
| Voltage | 80V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 12.5 Dia. x 25mm |
| Height | 25mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 10000h |
| Lead Pitch | 5mm |
| Ripple Current | 1.8A |
| Tolerance | ±20% |
| Series | FS |
| Leakage Current | 0.01 CV (After 2 Minutes) μA |
| Polarised | Polar |
| Dissipation Factor | 0.08% |
