KEMET 680μF Aluminium Electrolytic Capacitor 450V dc, Snap-In - ALA7DA681DF450
- RS Stock No.:
- 176-2521
- Mfr. Part No.:
- ALA7DA681DF450
- Brand:
- KEMET
8 In stock - FREE next working day delivery available
9 available from Europe for delivery within 1 working day(s).
Added
Price Each
£10.99
(exc. VAT)
£13.19
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £10.99 |
| 10 - 24 | £10.21 |
| 25 - 49 | £9.34 |
| 50 - 99 | £8.67 |
| 100 + | £7.91 |
- RS Stock No.:
- 176-2521
- Mfr. Part No.:
- ALA7DA681DF450
- Brand:
- KEMET
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- PT
Product Details
The KEMET ALA Snap-In Capacitors are designed for automotive applications. They can withstand vibration up to 20 G. The ALA7D capacitance values cover a range from 240 to 820 μF and voltage ranges of 400 to 500 V Applications:Typical applications for KEMET's ALA7D capacitors are mainly in the field of e-mobility, such as on an on-board chargers, inverters or wall boxes.
Designed for automotive usage
Vibration proof
Long life, up to 15,000 hours at +85°C (V r I r applied)
High ripple current
High voltage
Excellent surge voltage capability
PET sleeve
Vibration proof
Long life, up to 15,000 hours at +85°C (V r I r applied)
High ripple current
High voltage
Excellent surge voltage capability
PET sleeve
Specifications
Attribute | Value |
|---|---|
| Capacitance | 680µF |
| Voltage | 450V dc |
| Mounting Type | Snap-In |
| Technology | Aluminium Electrolytic |
| Dimensions | 35 Dia. x 50mm |
| Height | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Automotive Standard | AEC-Q200 |
| Leakage Current | 1.836 mA |
| Tolerance | ±20% |
| Polarised | Polar |
| Ripple Current | 3.06 (100 Hz) A, 6.49 (10 kHz) A |
| Equivalent Series Resistance | 135.4 (10 kHz) mΩ, 227.8 (100 Hz) mΩ |
| Series | ALA7D |
