KEMET 6800μF Aluminium Electrolytic Capacitor 450V dc, Screw Terminal - ALS31A682NT450

View all Aluminium Capacitors

Subtotal (1 box of 6 units)*

£566.388

(exc. VAT)

£679.668

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 15 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
6 +£94.398£566.39

*price indicative

RS Stock No.:
172-6962
Mfr. Part No.:
ALS31A682NT450
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Capacitance

6800µF

Voltage

450V dc

Mounting Type

Screw Terminal

Technology

Aluminium Electrolytic

Dimensions

77 (Dia.) x 220mm

Height

220mm

Depth

220mm

Minimum Operating Temperature

-40°C

Diameter

77mm

Maximum Operating Temperature

+85°C

Lead Pitch

31.8mm

Lifetime

20000 (Rated Voltage & Ripple Current at 85C) h, 40000 (Rated Voltage at 85C) h

Tolerance

±20%

Equivalent Series Resistance

14 (10 kHz 20C) mΩ, 21 (100 Hz 20C) mΩ

Ripple Current

27.4 (100Hz 85C) A, 38.8 (10kHz 85C) A

Series

ALS31

Leakage Current

6 mA

Polarised

Polar

COO (Country of Origin):
PT

KEMET ALS30/31 Series Screw Terminal Capacitors


KEMETS ALS30/31 aluminium electrolytic capacitors have various case sizes and voltage ratings. These screw terminal capacitors feature high ripple currents and long life performance. The capacitors are suitable for industrial and commercial applications which demand high reliability and long life expectancy.

Features


Compact in size
High ripple current
Good surge voltage capacity
Long life

Applications


Telecommunications
Power supplies
Process control
AC motor control
Welding
Traction


Clamp-fixing +85°C


Ideal for computer power supply applications or other applications that require long operational life
