Nichicon 22 μF Capacitor 450V dc, Radial, Through Hole - ULD2W220MHD6 Radial Lead
- RS Stock No.:
- 167-1157
- Mfr. Part No.:
- ULD2W220MHD6
- Brand:
- Nichicon
Bulk discount available
View bulk pricing optionsSubtotal (1 box of 50 units)*
£73.65
(exc. VAT)
£88.40
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 450 unit(s), ready to ship
Units | Per unit | Per Box* |
|---|---|---|
| 50 - 50 | £1.473 | £73.65 |
| 100 - 200 | £1.252 | £62.60 |
| 250 - 450 | £1.105 | £55.25 |
| 500 - 1950 | £0.957 | £47.85 |
| 2000 + | £0.884 | £44.20 |
*price indicative
- RS Stock No.:
- 167-1157
- Mfr. Part No.:
- ULD2W220MHD6
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Capacitor | |
| Capacitance | 22μF | |
| Voltage | 450V dc | |
| Construction | Radial Can | |
| Mount Type | Radial, Through Hole | |
| Packaging | Tape & Reel | |
| Polarity | Non-Polar | |
| Height | 20mm | |
| Length | 20mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 16mm | |
| Pin Count | 2 | |
| Termination Type | Radial Lead | |
| Capacitor Ripple Current | 525.6mA | |
| Maximum Operating Temperature | 105°C | |
| Lead Pitch | 7.5mm | |
| Standards/Approvals | RoHS | |
| Lifetime | 20000 h | |
| Automotive Standard | No | |
| Series | LD | |
| Tolerance | ±20 % | |
| Leakage Current | 1mA | |
| Dissipation Factor | 24% | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Capacitor | ||
Capacitance 22μF | ||
Voltage 450V dc | ||
Construction Radial Can | ||
Mount Type Radial, Through Hole | ||
Packaging Tape & Reel | ||
Polarity Non-Polar | ||
Height 20mm | ||
Length 20mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 16mm | ||
Pin Count 2 | ||
Termination Type Radial Lead | ||
Capacitor Ripple Current 525.6mA | ||
Maximum Operating Temperature 105°C | ||
Lead Pitch 7.5mm | ||
Standards/Approvals RoHS | ||
Lifetime 20000 h | ||
Automotive Standard No | ||
Series LD | ||
Tolerance ±20 % | ||
Leakage Current 1mA | ||
Dissipation Factor 24% | ||
- COO (Country of Origin):
- MY
Nichicon LD Series
Nichicon LD Series Aluminium Electrolytic Capacitor an extremely long load life of 12,000 to 20,000 hours at 105ºC. The LD series capacitors offer a high temperature range, high voltage, low impedance and high ripple current. This series is ideal for use in the power supply for LED lighting.
High reliability
High ripple current
Long life up to 20,000 hours
