Bulk discount available
Subtotal (1 bag of 1000 units)*
£219.00
(exc. VAT)
£263.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 06 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 1000 - 2000 | £0.219 | £219.00 |
| 3000 + | £0.20 | £200.00 |
*price indicative
- RS Stock No.:
- 181-5155
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Capacitance | 4.7μF | |
| Product Type | Capacitor | |
| Voltage | 450V dc | |
| Mount Type | Radial, Through Hole | |
| Construction | Radial Can | |
| Height | 16mm | |
| Length | 16mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 8mm | |
| Capacitor Ripple Current | 93mA | |
| Pin Count | 2 | |
| Termination Type | Radial Lead | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | RoHS | |
| Lifetime | 1000 h | |
| Lead Pitch | 3.5mm | |
| Leakage Current | 3μA | |
| Series | LPS | |
| Automotive Standard | No | |
| Tolerance | ±20 % | |
| Dissipation Factor | 17% | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Capacitance 4.7μF | ||
Product Type Capacitor | ||
Voltage 450V dc | ||
Mount Type Radial, Through Hole | ||
Construction Radial Can | ||
Height 16mm | ||
Length 16mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 8mm | ||
Capacitor Ripple Current 93mA | ||
Pin Count 2 | ||
Termination Type Radial Lead | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals RoHS | ||
Lifetime 1000 h | ||
Lead Pitch 3.5mm | ||
Leakage Current 3μA | ||
Series LPS | ||
Automotive Standard No | ||
Tolerance ±20 % | ||
Dissipation Factor 17% | ||
RS PRO Electrolytic Capacitor
The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 4.7μF, at a rated voltage of 450VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.
Features and Benefits
• Diameter is 8mm
• Dissipation factor is 17%
• Height is 16mm
• Lead pitch is 3.5mm
• Leakage current is 3μA
• Operating temperature ranging between -40°C and 105°C
• Ripple current is 93mA
• Working voltage is 450VDC
Applications
• Communication equipment
• Industrial measuring instruments
• Switching power supply
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
