Wurth Elektronik 10μF Aluminium Electrolytic Capacitor 25V dc, Surface Mount - 865250442003
- RS Stock No.:
- 163-6437
- Mfr. Part No.:
- 865250442003
- Brand:
- Wurth Elektronik
Available to back order for despatch 15/10/2024
Added
Price Each (On a Reel of 1000)
£0.136
(exc. VAT)
£0.163
(inc. VAT)
| Units | Per unit | Per Reel* |
| 1000 + | £0.136 | £136.00 |
| *price indicative | ||
- RS Stock No.:
- 163-6437
- Mfr. Part No.:
- 865250442003
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Wurth Elektronik SMD Non-Polar WCAP-ASNP Series Capacitors
WCAP-ASNP are non-polarised Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h @ +85°C
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
Specifications
Attribute | Value |
|---|---|
| Capacitance | 10µF |
| Voltage | 25V dc |
| Mounting Type | Surface Mount |
| Technology | Aluminium Electrolytic |
| Dimensions | 5.5 (Dia.) x 4.85mm |
| Height | 4.85mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 5.5mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 1.4mm |
| Ripple Current | 27mA |
| Leakage Current | 12.5 μA |
| Series | WCAP-ASNP |
| Polarised | Polar |
| Tolerance | ±20% |
| Dissipation Factor | 17 |
