Vishay 1000μF Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole - MAL225058102E3
- RS Stock No.:
- 159-5967
- Mfr. Part No.:
- MAL225058102E3
- Brand:
- Vishay
Bulk discount available
Subtotal (1 box of 100 units)*
£209.10
(exc. VAT)
£250.90
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 700 unit(s), ready to ship
Units | Per unit | Per Box* |
|---|---|---|
| 100 - 100 | £2.091 | £209.10 |
| 200 - 400 | £1.986 | £198.60 |
| 500 + | £1.882 | £188.20 |
*price indicative
- RS Stock No.:
- 159-5967
- Mfr. Part No.:
- MAL225058102E3
- Brand:
- Vishay
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Capacitance | 1000µF | |
| Voltage | 63V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 16.5 Dia. x 33.5mm | |
| Height | 33.5mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 16.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 10000h | |
| Lead Pitch | 7.5mm | |
| Leakage Current | 633 μA | |
| Tolerance | ±20% | |
| Series | RMI-V | |
| Automotive Standard | AEC-Q200 | |
| Ripple Current | 1.9A | |
| Polarised | Polar | |
| Dissipation Factor | 0.1% | |
Select all | ||
|---|---|---|
Brand Vishay | ||
Capacitance 1000µF | ||
Voltage 63V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 16.5 Dia. x 33.5mm | ||
Height 33.5mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 16.5mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 10000h | ||
Lead Pitch 7.5mm | ||
Leakage Current 633 μA | ||
Tolerance ±20% | ||
Series RMI-V | ||
Automotive Standard AEC-Q200 | ||
Ripple Current 1.9A | ||
Polarised Polar | ||
Dissipation Factor 0.1% | ||
