CHEMI-CON 2200μF Aluminium Electrolytic Capacitor 16V dc, Snap-In - EKMQ160ELL222MJ20S
- RS Stock No.:
- 144-7362
- Mfr. Part No.:
- EKMQ160ELL222MJ20S
- Brand:
- CHEMI-CON
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 144-7362
- Mfr. Part No.:
- EKMQ160ELL222MJ20S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 2200µF | |
| Voltage | 16V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10.5 (Dia.) x 21.5mm | |
| Height | 21.5mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 10.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Lifetime | 2000h | |
| Polarised | Polar | |
| Leakage Current | 4 μA | |
| Series | KMQ | |
| Tolerance | ±20% | |
| Ripple Current | 710mArms | |
| Dissipation Factor | 0.22% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 2200µF | ||
Voltage 16V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 10.5 (Dia.) x 21.5mm | ||
Height 21.5mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 10.5mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 5mm | ||
Lifetime 2000h | ||
Polarised Polar | ||
Leakage Current 4 μA | ||
Series KMQ | ||
Tolerance ±20% | ||
Ripple Current 710mArms | ||
Dissipation Factor 0.22% | ||
- COO (Country of Origin):
- JP
Downsized from current standard KMG series
Solvent resistant type except 160 to 450Vdc
(see PRECAUTIONS AND GUIDELINES)
RoHS2 Compliant
Solvent resistant type except 160 to 450Vdc
(see PRECAUTIONS AND GUIDELINES)
RoHS2 Compliant
