KEMET 6200μF Aluminium Electrolytic Capacitor 450V dc, Screw Terminal - ALS70A622NF450

View all Aluminium Capacitors

Subtotal (1 box of 12 units)*

£674.148

(exc. VAT)

£808.98

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
12 +£56.179£674.15

*price indicative

RS Stock No.:
144-3153
Mfr. Part No.:
ALS70A622NF450
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Capacitance

6200µF

Voltage

450V dc

Mounting Type

Screw Terminal

Technology

Aluminium Electrolytic

Dimensions

77 (Dia.) x 105mm

Height

105mm

Minimum Operating Temperature

-40°C

Diameter

77mm

Maximum Operating Temperature

+85°C

Lifetime

40000h

Lead Pitch

31.8mm

Leakage Current

6000 μA

Ripple Current

22.2A

Series

ALS70

Polarised

Polar

Tolerance

±20%

Equivalent Series Resistance

37mΩ

COO (Country of Origin):
PT
KEMET's ALS70/71 high CV screw terminal capacitors offer tremendous performance and reliability in a wide range of case sizes and voltage ratings, featuring high ripple current and long life performance. Volumetric efficiency ensures the maximum capacitance capability in a smaller size. They are ideally suited for industrial and commercial applications, demanding high reliability and long life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
