onsemi, 6.8V Zener Diode ±5% 500 mW SMT 2-Pin SOD-123
- RS Stock No.:
- 186-9335
- Mfr. Part No.:
- MMSZ6V8T1G
- Brand:
- onsemi
7800 In stock - FREE next working day delivery available
Price Each (In a Pack of 50)
£0.112
(exc. VAT)
£0.134
(inc. VAT)
| Units | Per unit | Per Pack* |
| 50 - 50 | £0.112 | £5.60 |
| 100 - 200 | £0.075 | £3.75 |
| 250 - 450 | £0.074 | £3.70 |
| 500 - 950 | £0.072 | £3.60 |
| 1000 + | £0.071 | £3.55 |
| *price indicative | ||
- RS Stock No.:
- 186-9335
- Mfr. Part No.:
- MMSZ6V8T1G
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
Three complete series of Zener diodes are offered in the convenient, surface mount plastic SOD-123 package. These devices provide a convenient alternative to the lead less 34-package style.
501 mW Rating on FR-4 or FR-5 Board
Wide Zener Reverse Voltage Range - 2.4 V to 56 V
Package Designed for Optimal Automated Board Assembly
Small Package Size for High Density Applications
Mechanical Characteristics:
CASE: Void-free, transfer-Moulded, ther
Wide Zener Reverse Voltage Range - 2.4 V to 56 V
Package Designed for Optimal Automated Board Assembly
Small Package Size for High Density Applications
Mechanical Characteristics:
CASE: Void-free, transfer-Moulded, ther
Specifications
Attribute | Value |
|---|---|
| Diode Configuration | Single |
| Nominal Zener Voltage | 6.8V |
| Number of Elements per Chip | 1 |
| Mounting Type | Surface Mount |
| Maximum Power Dissipation | 500 mW |
| Package Type | SOD-123 |
| Zener Type | Voltage Regulator |
| Zener Voltage Tolerance | ±5% |
| Pin Count | 2 |
| Test Current | 5mA |
| Maximum Zener Impedance | 15 Ω @ 5 mA, 80 Ω @ 1 mA |
| Maximum Reverse Leakage Current | 2µA |
| Dimensions | 2.84 x 1.8 x 1.25mm |
| Forward Voltage | 0.9V |
| Automotive Standard | AEC-Q101 |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +150 °C |
| Forward Current | 10mA |
