Molex, 172762 Plug Connector Housing, 4.2mm Pitch, 18 Way, 2 Row

This connector housing is a miniature component within the Mini-Fit Family Power Connectors, designed specifically for power and wire-to-board or wire-to-wire applications. With a length of 26mm and compatibility for 18 circuits across dual rows, this panel mount connector features a pitch of 4.2mm and a straight body orientation. Constructed from durable nylon, it is engineered to withstand operational temperatures ranging from -40°C to +105°C.

• 18 contacts enhance functionality for complex connections
• Panel mount design facilitates secure installation in various settings
• 4.2mm pitch ensures compatibility with related connectors
• Dual row layout maximises space efficiency in compact designs
• Glow-wire capable for improved safety during operation
• Nylon construction provides excellent resilience and durability

• Used with Mini-Fit TPA2/Sigma Male Terminal for robust connections
• Implemented in automation systems for reliable power distribution
• Compatible with Mini-Fit Sigma receptacle housing for versatile configurations
• Suitable for domestic and industrial electrical systems requiring secure connections

The housing is made from nylon, ensuring durability and resistance to environmental factors.

The glow-wire capability enhances safety by ensuring that the housing can withstand high temperatures without compromising performance.

The straight orientation allows for straightforward installation and connection, making it ideal for tight spaces and simplified assembly.

Yes, the connector is designed to be compatible with lead-free solder processes, addressing modern manufacturing standards.

This housing is capable of functioning within a temperature range of -40°C to +105°C, allowing for versatile application in various environments.
