STMicroelectronics Voltage Supervisor 10-Pin DFN-10, STEF512SRXCPUR

View all Voltage Supervisors
Bulk discount available

Subtotal (1 pack of 2 units)*

£4.36

(exc. VAT)

£5.24

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 490 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
Per Pack*
2 - 8£2.18£4.36
10 - 18£2.065£4.13
20 - 48£1.865£3.73
50 - 98£1.68£3.36
100 +£1.595£3.19

*price indicative

Packaging Options:
RS Stock No.:
249-6747
Mfr. Part No.:
STEF512SRXCPUR
Brand:
STMicroelectronics
Find similar products by selecting one or more attributes.
Select all

Brand

STMicroelectronics

Product Type

Voltage Supervisor

Watchdog Timer

No

Manual Reset

No

Power Fail Detection

No

Output Driver

Active Low

Mount Type

Surface

Package Type

DFN-10

Pin Count

10

Reset Active Time

13ms

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

125°C

Series

STEF512SRX

Standards/Approvals

RoHS

Minimum Supply Voltage

-0.3V

Automotive Standard

No

Maximum Supply Voltage

25V

The STMicroelectronics integrated dual electronic fuse, designed to protect circuitry on the output from overcurrent and overvoltage events, in those applications requiring hot swap operation and inrush current control. The device embeds two electronic fuses, one for the 5 V rail and one for the 12 V rail.

25 V absolute maximum input voltage

Precise output overvoltage clamp

Fixed overcurrent protection for both channels

Reverse current protection on 5 V channel

Thermal protection

SAS disable pin

Current monitor pin selection

Current monitor output in a single pin for both rails
