Microchip Voltage Supervisor 4.63V max. 3-Pin SOT-23, MIC2790N-04VD6-TR
- RS Stock No.:
- 649-477
- Mfr. Part No.:
- MIC2790N-04VD6-TR
- Brand:
- Microchip
Bulk discount available
Subtotal (1 tape of 5 units)*
£4.13
(exc. VAT)
£4.955
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
---|---|---|
5 - 45 | £0.826 | £4.13 |
50 - 245 | £0.726 | £3.63 |
250 - 495 | £0.652 | £3.26 |
500 + | £0.562 | £2.81 |
*price indicative
- RS Stock No.:
- 649-477
- Mfr. Part No.:
- MIC2790N-04VD6-TR
- Brand:
- Microchip
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Microchip | |
Voltage Supervisor Type | Power On Reset Circuit | |
Number of Supervisors | 1 | |
Watchdog Timer | No | |
Manual Reset | No | |
Maximum Reset Threshold Voltage | 4.63V | |
Power Fail Detection | No | |
Package Type | SOT-23 | |
Pin Count | 3 | |
Select all | ||
---|---|---|
Brand Microchip | ||
Voltage Supervisor Type Power On Reset Circuit | ||
Number of Supervisors 1 | ||
Watchdog Timer No | ||
Manual Reset No | ||
Maximum Reset Threshold Voltage 4.63V | ||
Power Fail Detection No | ||
Package Type SOT-23 | ||
Pin Count 3 | ||
- COO (Country of Origin):
- TH
The Microchip Voltage supervisor IC features a manual reset input, enable input (MIC2793 only), a capacitor-programmable reset timeout delay and both an active-low and active-high reset output. The MIC2790/1/3 monitors system voltages that are in the range of 0.4V to 5.5V, with a typical sense accuracy of 0.5% at +25°C and ±1.0% across −40°C to +125°C. The IC asserts a reset output when the sense voltage drops below the threshold or when the manual reset is pulled to a logic low. The active-low reset stays low for the duration of the reset timeout delay once the sense voltage returns to normal and the manual reset transitions to a logic high state.
1.5V to 5.5V operating supply voltage range
Ultra-fast propagation delay (1μs typically)
±1.0% threshold accuracy from −40°C to +125°C
Monitored voltage range from 0.4V to 5.5V
Programmable reset timeout delay (from 1ms to 10s)
Manual reset input with an internal pull-up resistor
Ultra-fast propagation delay (1μs typically)
±1.0% threshold accuracy from −40°C to +125°C
Monitored voltage range from 0.4V to 5.5V
Programmable reset timeout delay (from 1ms to 10s)
Manual reset input with an internal pull-up resistor
