Microchip MIC2954-08YM, 1 Low Dropout Voltage, Voltage Regulator 250mA, 1.24 → 29 V 8-Pin, SOIC

View all Voltage Regulators
Bulk discount available

Subtotal (1 tube of 95 units)*

£105.45

(exc. VAT)

£126.35

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1,045 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tube*
95 - 95£1.11£105.45
190 +£1.067£101.37

*price indicative

RS Stock No.:
177-0370
Mfr. Part No.:
MIC2954-08YM
Brand:
Microchip
Find similar products by selecting one or more attributes.
Select all

Brand

Microchip

Regulator Type

Low Dropout Voltage

Maximum Output Current

250mA

Output Voltage

1.24 → 29 V

Number of Outputs

1

Line Regulation

0.4 %/V

Load Regulation

0.3 %/V

Accuracy

1%

Mounting Type

Surface Mount

Package Type

SOIC

Quiescent Current

120µA

Pin Count

8

Reference Voltage

1.27V

Output Type

Adjustable

Dimensions

4.93 x 3.94 x 1.48mm

Maximum Operating Temperature

+125 °C

Minimum Input Voltage

2 V

Minimum Operating Temperature

-40 °C

Height

1.48mm

Maximum Input Voltage

30 V

Width

3.94mm

Length

4.93mm

The MIC2954 is a "bulletproof", efficient voltage regulator with very low dropout voltage (typically 40mV at light loads and 375mV at 250mA) and low quiescent current (120μA typical). The quiescent current of the MIC2954 increases only slightly in dropout, thus prolonging battery life.

High-accuracy: 5V, guaranteed 250mA output
Low quiescent current
Low dropout voltage
Extremely tight load and line regulation
Very low temperature coefficient
Current and thermal limiting
High-accuracy: 5V, guaranteed 250mA output
Low quiescent current
Low dropout voltage
Extremely tight load and line regulation
Very low temperature coefficient
Current and thermal limiting
Input can withstand -20V reverse battery and +60V positive transients
Error flag warns of low output voltage
Logic-controlled electronic shutdown
Output programmable from 1.24V to 29V (MIC2954-07/08)
Available in TO-220, TO-92, and surface-mount SOT-223 and SOP-8 packages
