Bourns, CV Disc Varistor 280 pF 2500 A, Clamping 775 V, Varistor 470 V, Disc (10 mm)
- RS Stock No.:
- 245-9090
- Mfr. Part No.:
- CV300K10BL1
- Brand:
- Bourns
Subtotal (1 bag of 500 units)*
£118.00
(exc. VAT)
£141.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 5,500 unit(s) shipping from 16 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 500 + | £0.236 | £118.00 |
*price indicative
- RS Stock No.:
- 245-9090
- Mfr. Part No.:
- CV300K10BL1
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Varistor Voltage | 470 V | |
| Product Type | Disc Varistor | |
| Packaging | Tape & Reel | |
| Clamping Voltage VC | 775V | |
| Clamping Current | 2500A | |
| Mount Type | Through Hole | |
| Series | CV | |
| Maximum AC Voltage | 300V ac | |
| Diameter | 12.5 mm | |
| Maximum DC Voltage | 385V dc | |
| Maximum Surge Current | 2500A | |
| Capacitance | 280pF | |
| Length | 15mm | |
| Minimum Operating Temperature | -40°C | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | RoHS, UL | |
| Termination Style | Radial | |
| Thickness | 6.1mm | |
| Package/Case | Disc (10 mm) | |
| Automotive Standard | AEC-Q200 | |
| Energy Rating | 82J | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Varistor Voltage 470 V | ||
Product Type Disc Varistor | ||
Packaging Tape & Reel | ||
Clamping Voltage VC 775V | ||
Clamping Current 2500A | ||
Mount Type Through Hole | ||
Series CV | ||
Maximum AC Voltage 300V ac | ||
Diameter 12.5 mm | ||
Maximum DC Voltage 385V dc | ||
Maximum Surge Current 2500A | ||
Capacitance 280pF | ||
Length 15mm | ||
Minimum Operating Temperature -40°C | ||
Pin Count 2 | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals RoHS, UL | ||
Termination Style Radial | ||
Thickness 6.1mm | ||
Package/Case Disc (10 mm) | ||
Automotive Standard AEC-Q200 | ||
Energy Rating 82J | ||
- COO (Country of Origin):
- SI
The Bourns CV series of transient surge suppressors are disc shaped varistor designed to be operated continuously in low and medium voltage electronic system circuits as well as across AC power lines. Due to their radial lead construction, these component require very little mounting space.
Operating ambient temperature range from -40°C to 85°C
Surge protection
Fast response time
