Bourns, ZVHT Varistor 6.5 nF 10 A, Clamping 54 V, Varistor 33 V, 2220
- RS Stock No.:
- 204-8785
- Mfr. Part No.:
- ZV20K2220122NIR1HT
- Brand:
- Bourns
Bulk discount available
Subtotal (1 pack of 10 units)*
£7.11
(exc. VAT)
£8.53
(inc. VAT)
Add 80 units to get free delivery
In Stock
- 560 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 90 | £0.711 | £7.11 |
| 100 - 490 | £0.626 | £6.26 |
| 500 + | £0.574 | £5.74 |
*price indicative
- RS Stock No.:
- 204-8785
- Mfr. Part No.:
- ZV20K2220122NIR1HT
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Varistor | |
| Varistor Voltage | 33 V | |
| Packaging | Tape & Reel | |
| Clamping Voltage VC | 54V | |
| Clamping Current | 10A | |
| Mount Type | Surface | |
| Series | ZVHT | |
| Maximum AC Voltage | 20V ac | |
| Maximum Surge Current | 1.2kA | |
| Maximum DC Voltage | 26V dc | |
| Capacitance | 6.5nF | |
| Minimum Operating Temperature | -55°C | |
| Length | 5.7mm | |
| Maximum Operating Temperature | 150°C | |
| Standards/Approvals | UL, RoHS | |
| Termination Style | Surface Mount | |
| Thickness | 1.25mm | |
| Depth | 5mm | |
| Package/Case | 2220 | |
| Energy Rating | 8J | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Varistor | ||
Varistor Voltage 33 V | ||
Packaging Tape & Reel | ||
Clamping Voltage VC 54V | ||
Clamping Current 10A | ||
Mount Type Surface | ||
Series ZVHT | ||
Maximum AC Voltage 20V ac | ||
Maximum Surge Current 1.2kA | ||
Maximum DC Voltage 26V dc | ||
Capacitance 6.5nF | ||
Minimum Operating Temperature -55°C | ||
Length 5.7mm | ||
Maximum Operating Temperature 150°C | ||
Standards/Approvals UL, RoHS | ||
Termination Style Surface Mount | ||
Thickness 1.25mm | ||
Depth 5mm | ||
Package/Case 2220 | ||
Energy Rating 8J | ||
Automotive Standard No | ||
- COO (Country of Origin):
- SI
The Bourns ZVHT series low voltage multi-layered varistor with 6500pF capacitance is designed to protect sensitive electronic devices against high voltage surges in the low voltage region.
Broad range of current and energy handling capabilities
Short response time
Low sensitivity
RoHS compliant
