Amphenol Socapex, Panel Female- 1 Port Type USB Type A IP68 USB Connector USB 3.2 Gen 1
- RS Stock No.:
- 597-498
- Mfr. Part No.:
- USBFTV7PE2G
- Brand:
- Amphenol Socapex
Subtotal (1 unit)*
£72.53
(exc. VAT)
£87.04
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 21 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £72.53 |
*price indicative
- RS Stock No.:
- 597-498
- Mfr. Part No.:
- USBFTV7PE2G
- Brand:
- Amphenol Socapex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Socapex | |
| Product Type | USB Connector | |
| Mount Type | Panel | |
| USB Type | USB Type A | |
| Current | 5A | |
| USB Specification | USB 3.2 Gen 1 | |
| Connector Gender | Female | |
| IP Rating | IP68 | |
| Number of Ports | 1 | |
| Voltage | 20V | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Cable | |
| Contact Material | Polycarbonate | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | MIL-DTL-38999 Series III, MIL-DTL-26482, UL94 V0, EN45545, RoHS | |
| Hazardous Area Certification | ATEX | |
| Series | USB | |
| Select all | ||
|---|---|---|
Brand Amphenol Socapex | ||
Product Type USB Connector | ||
Mount Type Panel | ||
USB Type USB Type A | ||
Current 5A | ||
USB Specification USB 3.2 Gen 1 | ||
Connector Gender Female | ||
IP Rating IP68 | ||
Number of Ports 1 | ||
Voltage 20V | ||
Minimum Operating Temperature -40°C | ||
Termination Type Cable | ||
Contact Material Polycarbonate | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals MIL-DTL-38999 Series III, MIL-DTL-26482, UL94 V0, EN45545, RoHS | ||
Hazardous Area Certification ATEX | ||
Series USB | ||
Non Compliant
- COO (Country of Origin):
- IN
The Amphenol Socapex Rugged USB Type-A connector designed for harsh environments, featuring sealed protection against fluids and dust. It offers shock, vibration, and traction resistance, making it ideal for demanding applications. With an olive drab finish and solder pin termination, it ensures secure and reliable connectivity.
IP68 protection
Improved EMI protection
Jam nut receptacle
Metal backshell
