Alpha Wire Alpha Essentials Communication & Control Series Data Cable 7 Pairs 7 Cores 30 m Grey Sheath Polyvinyl
- RS Stock No.:
- 187-1872
- Mfr. Part No.:
- 1067 SL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£297.15
(exc. VAT)
£356.58
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 05 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 30 + | £9.905 | £297.15 |
*price indicative
- RS Stock No.:
- 187-1872
- Mfr. Part No.:
- 1067 SL005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Number of Pairs | 7 | |
| Product Type | Data Cable | |
| Number of Cores | 7 | |
| Cable Length | 30m | |
| Jacket Colour | Grey | |
| Outside Diameter | 12.42mm | |
| Minimum Operating Temperature | -20°C | |
| Jacket Material | Polyvinyl Chloride | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | CE, UL | |
| Number of Strands | 19 | |
| Voltage | 300V | |
| Series | Alpha Essentials Communication & Control | |
| Size of Strands | 110μm | |
| Conductor Material | Tin Copper Wire | |
| Fire Behaviour | VW-1 | |
| Core Strands | 19 x 110 μm | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Number of Pairs 7 | ||
Product Type Data Cable | ||
Number of Cores 7 | ||
Cable Length 30m | ||
Jacket Colour Grey | ||
Outside Diameter 12.42mm | ||
Minimum Operating Temperature -20°C | ||
Jacket Material Polyvinyl Chloride | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals CE, UL | ||
Number of Strands 19 | ||
Voltage 300V | ||
Series Alpha Essentials Communication & Control | ||
Size of Strands 110μm | ||
Conductor Material Tin Copper Wire | ||
Fire Behaviour VW-1 | ||
Core Strands 19 x 110 μm | ||
Our line-up of standard communication and control cables gives you maximum choice and fewer trade-offs. By offering you a comprehensive collection of insulation/jacketing materials, shielding options, and conductor counts, you can easily select the cable that meets your most demanding needs. We have cables that go beyond the ordinary to satisfy rigorous requirements of EMI performance, transmission distances, flexibility, and temperature extremes.
Audio systems: speakers, microphones, intercoms
Broadcast and studio
Data transmission: RS-232, 422, 485
CAD/CAM
Computer peripherals
Business machines
Security systems: alarms, cameras, sensors
Control systems
Instrumentation systems
Point-of-sale systems
Banking systems
