STMicroelectronics ESDAVLC8-1BU2, Bi-Directional TVS Diode, 2-Pin ST-0201
- RS Stock No.:
- 829-0292
- Mfr. Part No.:
- ESDAVLC8-1BU2
- Brand:
- STMicroelectronics
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (On a Tape of 100)
£0.068
(exc. VAT)
£0.082
(inc. VAT)
- RS Stock No.:
- 829-0292
- Mfr. Part No.:
- ESDAVLC8-1BU2
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Diode Configuration | Single | |
| Direction Type | Bi-Directional | |
| Minimum Breakdown Voltage | 14.5V | |
| Mounting Type | Surface Mount | |
| Package Type | ST-0201 | |
| Maximum Reverse Stand-off Voltage | 3V | |
| Pin Count | 2 | |
| Maximum Peak Pulse Current | 1.5A | |
| ESD Protection | Yes | |
| Number of Elements per Chip | 1 | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +125 °C | |
| Dimensions | 0.65 x 0.35 x 0.33mm | |
| Length | 0.65mm | |
| Width | 0.35mm | |
| Height | 0.33mm | |
| Maximum Reverse Leakage Current | 100nA | |
Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Diode Configuration Single | ||
Direction Type Bi-Directional | ||
Minimum Breakdown Voltage 14.5V | ||
Mounting Type Surface Mount | ||
Package Type ST-0201 | ||
Maximum Reverse Stand-off Voltage 3V | ||
Pin Count 2 | ||
Maximum Peak Pulse Current 1.5A | ||
ESD Protection Yes | ||
Number of Elements per Chip 1 | ||
Minimum Operating Temperature -40 °C | ||
Maximum Operating Temperature +125 °C | ||
Dimensions 0.65 x 0.35 x 0.33mm | ||
Length 0.65mm | ||
Width 0.35mm | ||
Height 0.33mm | ||
Maximum Reverse Leakage Current 100nA | ||
Transil™ Array Unidirectional for ESD Protection, ESDA Series, STMicroelectronics
Transient Voltage Suppressors, STMicroelectronics
