Vishay VTVS5V0ASMF-M3-08, Uni-Directional TVS Diode, 400W, 2-Pin DO-219AB
- RS Stock No.:
- 180-6533
- Mfr. Part No.:
- VTVS5V0ASMF-M3-08
- Brand:
- Vishay
Subtotal (1 reel of 3000 units)*
£261.00
(exc. VAT)
£312.00
(inc. VAT)
FREE delivery for orders over £50.00
- Plus 33,000 unit(s) shipping from 06 October 2025
Units | Per unit | Per Reel* |
---|---|---|
3000 + | £0.087 | £261.00 |
*price indicative
- RS Stock No.:
- 180-6533
- Mfr. Part No.:
- VTVS5V0ASMF-M3-08
- Brand:
- Vishay
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Direction Type | Uni-Directional | |
Diode Configuration | Single | |
Maximum Clamping Voltage | 8.9V | |
Minimum Breakdown Voltage | 6.4V | |
Mounting Type | Surface Mount | |
Package Type | DO-219AB | |
Maximum Reverse Stand-off Voltage | 5V | |
Pin Count | 2 | |
Peak Pulse Power Dissipation | 400W | |
Maximum Peak Pulse Current | 42.95A | |
ESD Protection | Yes | |
Number of Elements per Chip | 1 | |
Minimum Operating Temperature | -55 °C | |
Dimensions | 2.9 x 1.9 x 0.98mm | |
Maximum Operating Temperature | +175 °C | |
Maximum Reverse Leakage Current | 5µA | |
Test Current | 1mA | |
Width | 1.9mm | |
Length | 2.9mm | |
Height | 0.98mm | |
Capacitance | 2.095nF | |
Automotive Standard | AEC-Q101 | |
Select all | ||
---|---|---|
Brand Vishay | ||
Direction Type Uni-Directional | ||
Diode Configuration Single | ||
Maximum Clamping Voltage 8.9V | ||
Minimum Breakdown Voltage 6.4V | ||
Mounting Type Surface Mount | ||
Package Type DO-219AB | ||
Maximum Reverse Stand-off Voltage 5V | ||
Pin Count 2 | ||
Peak Pulse Power Dissipation 400W | ||
Maximum Peak Pulse Current 42.95A | ||
ESD Protection Yes | ||
Number of Elements per Chip 1 | ||
Minimum Operating Temperature -55 °C | ||
Dimensions 2.9 x 1.9 x 0.98mm | ||
Maximum Operating Temperature +175 °C | ||
Maximum Reverse Leakage Current 5µA | ||
Test Current 1mA | ||
Width 1.9mm | ||
Length 2.9mm | ||
Height 0.98mm | ||
Capacitance 2.095nF | ||
Automotive Standard AEC-Q101 | ||
- COO (Country of Origin):
- CN
Tolerance of the avalanche breakdown voltage ± 5 % VTVSxxxA... ± 2 % VTVSxxxG...
Low-profile package
