10 kΩ, Surface Mount Trimmer Potentiometer, J-Hook 0.25 W Top Adjust Bourns, PVG5
- RS Stock No.:
- 669-6691
- Distrelec Article No.:
- 302-86-073
- Mfr. Part No.:
- PVG5A103C03R00
- Brand:
- Bourns
Bulk discount available
Subtotal (1 unit)*
£2.39
(exc. VAT)
£2.87
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 42 unit(s) shipping from 04 May 2026
- Plus 406 unit(s) shipping from 11 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £2.39 |
| 25 - 49 | £2.23 |
| 50 - 99 | £2.10 |
| 100 - 249 | £1.95 |
| 250 + | £1.77 |
*price indicative
- RS Stock No.:
- 669-6691
- Distrelec Article No.:
- 302-86-073
- Mfr. Part No.:
- PVG5A103C03R00
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Trimmer Potentiometer | |
| Maximum Resistance | 10kΩ | |
| Mount Type | Surface Mount | |
| Number of Turns | 12 | |
| Packaging | Tape & Reel | |
| Orientation | Top Adjust | |
| Power Rating | 0.25W | |
| Series | PVG5 | |
| Termination Style | J-Hook | |
| Automotive Standard | No | |
| Tolerance ± | 10% | |
| Temperature Coefficient | ±150 ppm/°C | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Shaft Diameter | 1.5mm | |
| Length | 4.8mm | |
| Shaft Length | 0.6mm | |
| Standards/Approvals | RoHS, IPC, ISO, EIAJ, VECI, EIA | |
| Depth | 3.9mm | |
| Height | 5.1mm | |
| Element Material | Cermet | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Trimmer Potentiometer | ||
Maximum Resistance 10kΩ | ||
Mount Type Surface Mount | ||
Number of Turns 12 | ||
Packaging Tape & Reel | ||
Orientation Top Adjust | ||
Power Rating 0.25W | ||
Series PVG5 | ||
Termination Style J-Hook | ||
Automotive Standard No | ||
Tolerance ± 10% | ||
Temperature Coefficient ±150 ppm/°C | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Shaft Diameter 1.5mm | ||
Length 4.8mm | ||
Shaft Length 0.6mm | ||
Standards/Approvals RoHS, IPC, ISO, EIAJ, VECI, EIA | ||
Depth 3.9mm | ||
Height 5.1mm | ||
Element Material Cermet | ||
11-Turn 250mW 5mm Top Adjust PVG5A Series
11 turn high resolution trimmers permitting accurate adjustment
Compatible with the VPS wave soldering standard and passing through the ultra-sounds tank
Clutch mechanism prevents excessive wiper rotation
Applications: sensors, industrial machines, CPU's, measuring instruments
Multi-Turn Surface Mount Trimmers
