TE Connectivity Toggle Switch, Panel Mount, On-(On), SPDT, Solder Terminal
- RS Stock No.:
- 745-5606
- Mfr. Part No.:
- 6-6437630-3
- Brand:
- TE Connectivity
Discontinued
- RS Stock No.:
- 745-5606
- Mfr. Part No.:
- 6-6437630-3
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Contact Configuration | SPDT | |
| Switch Operation | On-(On) | |
| Contact Current Rating | 400 mA @ 20 V dc | |
| Mounting Type | Panel Mount | |
| Terminal Type | Solder | |
| Panel Cut Out Diameter | 6.2mm | |
| Actuator Length | 10.5mm | |
| Actuator Material | Chromium Plated Brass | |
| Panel Cut Out Size | 6.2mm | |
| Contact Resistance | 10mΩ | |
| Contact Material | Gold Plated Brass Alloy | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +70°C | |
| Mechanical Life | 50000Cycles | |
| Operating Temperature Range | -20 → +70°C | |
| Priced to Clear | Yes | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Contact Configuration SPDT | ||
Switch Operation On-(On) | ||
Contact Current Rating 400 mA @ 20 V dc | ||
Mounting Type Panel Mount | ||
Terminal Type Solder | ||
Panel Cut Out Diameter 6.2mm | ||
Actuator Length 10.5mm | ||
Actuator Material Chromium Plated Brass | ||
Panel Cut Out Size 6.2mm | ||
Contact Resistance 10mΩ | ||
Contact Material Gold Plated Brass Alloy | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +70°C | ||
Mechanical Life 50000Cycles | ||
Operating Temperature Range -20 → +70°C | ||
Priced to Clear Yes | ||
TE Connectivity Panel Mount Toggle Switch - FT Ultraminiature Series
FT ultraminiature series panel mount toggle switches with M6 x 0.75mm threaded bushing that conforms to standard panel cut outs. These panel mount toggle switches have hooking type lead wire solder terminations and silver plated copper alloy contacts. Typical uses for these ultraminiature series panel mount toggle switches include light to medium duty applications such as industrial, instrumentation and medical equipment.
