APEM Rotary Switch, Panel Mount, (On)-Off-(On), SPST, Solder Terminal

RS Stock No.:: 103-5495
Mfr. Part No.:: 5637A9
Brand:: APEM

APEM Rotary Switch, Panel Mount, (On)-Off-(On), SPST, Solder Terminal

522 In stock - FREE next working day delivery available

51 available from Europe for delivery within 1 working day(s).

Added

Price Each

£9.59

(exc. VAT)

£11.51

(inc. VAT)

Units	Per unit
1 - 24	£9.59
25 - 49	£7.86
50 - 99	£7.21
100 - 249	£6.71
250 +	£6.14

RS Stock No.:: 103-5495
Mfr. Part No.:: 5637A9
Brand:: APEM

Technical Reference

Legislation and Compliance

COO (Country of Origin):: FR

Product Details

Toggle Switches, Flat Lever

Panel mount switches with a large variety of contact configurations
Solder lug termination. Bush thread 1/4 - 40UNS (6.35 - 4UNS)
Brass actuator and Diallyl Phthalate case
Silver contacts
Panel cut-out 6.5 mm

Note

For biased switches '(on)' refers to momentary 'on' position

Approvals

UL; CSA; CECC; LNZ; GAM T1; QPL (Europe); MUAHAG; NATO

Approvals

UL; CSA; CECC; LNZ; GAM T1; (Europe); MUAHAG; NATO; VDE

Specifications

Attribute	Value
Contact Configuration	SPST
Switch Operation	(On)-Off-(On)
Contact Current Rating	4 A @ 30 V dc
Mounting Type	Panel Mount
Terminal Type	Solder
Actuator Length	11.4mm
Actuator Material	Brass
Contact Resistance	0.01Ω
Contact Material	Silver
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+85°C
Operating Temperature Range	-40 → +85°C
Mechanical Life	100000Operations
