OPTIBELT 25 AT5 / 420 Timing Belt, 84 Teeth, 420mm Length, 25mm Width
- RS Stock No.:
- 175-3061
- Mfr. Part No.:
- 25 AT5 / 420
- Brand:
- OPTIBELT
Bulk discount available
Subtotal (1 unit)*
£25.65
(exc. VAT)
£30.78
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 47 unit(s) ready to ship from another location
- Plus 30 unit(s) shipping from 25 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £25.65 |
| 5 - 9 | £24.62 |
| 10 - 24 | £24.13 |
| 25 + | £23.60 |
*price indicative
- RS Stock No.:
- 175-3061
- Mfr. Part No.:
- 25 AT5 / 420
- Brand:
- OPTIBELT
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | OPTIBELT | |
| Length | 420mm | |
| Width | 25mm | |
| Pitch | 5mm | |
| Number of Teeth | 84 | |
| Profile | AT5 | |
| Material | Polyurethane | |
| Series | ALPHA TORQUE | |
| Tooth Height | 1.2mm | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | +80°C | |
Select all | ||
|---|---|---|
Brand OPTIBELT | ||
Length 420mm | ||
Width 25mm | ||
Pitch 5mm | ||
Number of Teeth 84 | ||
Profile AT5 | ||
Material Polyurethane | ||
Series ALPHA TORQUE | ||
Tooth Height 1.2mm | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature +80°C | ||
- COO (Country of Origin):
- IE
Performance molded polyurethane timing belts that perform engineered to perform better than standard urethane belts. Capable of handling a wide variety or applications. Increased operation temperature range of ranges -20 to 176°F.
Polyurethane material engineered to provide superior performance from standard polyurethane timing belts.
Capable of handling a wide variety or applications.
Increased operation range -20 to 176°F.
Capable of handling a wide variety or applications.
Increased operation range -20 to 176°F.
