OPTIBELT 645 5MHP 9 Timing Belt, 129 Teeth, 645mm Length, 9mm Width
- RS Stock No.:
- 212-993
- Mfr. Part No.:
- 645 5MHP 9
- Brand:
- OPTIBELT
Subtotal (1 unit)*
£9.51
(exc. VAT)
£11.41
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £9.51 |
*price indicative
- RS Stock No.:
- 212-993
- Mfr. Part No.:
- 645 5MHP 9
- Brand:
- OPTIBELT
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | OPTIBELT | |
Length | 645mm | |
Width | 9mm | |
Pitch | 5mm | |
Number of Teeth | 129 | |
Profile | 5MHP | |
Material | Rubber | |
Series | OMEGA HP | |
Tooth Height | 1.9mm | |
Minimum Operating Temperature | -30°C | |
Maximum Operating Temperature | +100°C | |
Select all | ||
---|---|---|
Brand OPTIBELT | ||
Length 645mm | ||
Width 9mm | ||
Pitch 5mm | ||
Number of Teeth 129 | ||
Profile 5MHP | ||
Material Rubber | ||
Series OMEGA HP | ||
Tooth Height 1.9mm | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature +100°C | ||
- COO (Country of Origin):
- DE
The optibelt OMEGA HP high performance timing belt was especially developed for heavily loaded, high speed drives. Improved materials and highly developed process engineering are the basis for this very high performance level. Faster, stronger, more compact that's how the new optibelt OMEGA HP presents itself. A timing belt to meet the highest demands.
High precision
For HTD and RPP pulleys
Profiles 8MHP and 14MHP and are electrically conductive
Up to two times the power transmission capability of standard OMEGA
Abrasion resistant fabric with low friction and shear resistant teeth
Fiberglass cord
For HTD and RPP pulleys
Profiles 8MHP and 14MHP and are electrically conductive
Up to two times the power transmission capability of standard OMEGA
Abrasion resistant fabric with low friction and shear resistant teeth
Fiberglass cord
