TE Connectivity 7000 Series Panel Mount Timer Relay, 2-Contact, 0.5 → 5s, DPDT
- RS Stock No.:
- 782-1475
- Mfr. Part No.:
- 7022AB
- Brand:
- TE Connectivity
Discontinued product
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 782-1475
- Mfr. Part No.:
- 7022AB
- Brand:
- TE Connectivity
Technical Reference
Legislation and Compliance
Non Compliant
- COO (Country of Origin):
- US
Product Details
7000 Series - Electropneumatic Timing Relay, off-delay
The 7000 Series is a range of industrial electropneumatic timing relay.
This series convinced by a calibrated timing head, a precision-wound potted coil and a snap-action switch assembly.
This series convinced by a calibrated timing head, a precision-wound potted coil and a snap-action switch assembly.
Off-delay function
Oversized time-calibrated adjustment knobs
Markings visible from all angles
Inherent transient immunity
Available in 2-pole or 4-pole models
Surface-mount, panel-mount or octal plug-in mounting
Front terminals are “Easy-to-Reach” screw terminals, all on the face of the unit
Module assembly with timing head, coil assembly and switch-block are individual modules
Oversized time-calibrated adjustment knobs
Markings visible from all angles
Inherent transient immunity
Available in 2-pole or 4-pole models
Surface-mount, panel-mount or octal plug-in mounting
Front terminals are “Easy-to-Reach” screw terminals, all on the face of the unit
Module assembly with timing head, coil assembly and switch-block are individual modules
Specifications
Attribute | Value |
|---|---|
| Mounting Type | Panel Mount |
| Mode of Operation | OFF Delay |
| Time Range | 0.5 → 5s |
| Number of Contacts | 2 |
| Contact Configuration | DPDT |
| Time Increment | Seconds |
| Maximum Current | 15A |
| Maximum Voltage | 30 V dc, 600V ac |
| Switch Configuration | DPDT |
| Terminal Type | Screw |
| Width | 82.5mm |
| Series | 7000 |
| Maximum Operating Temperature | +75°C |
| Depth | 78.486mm |
| Length | 158.2mm |
| Minimum Operating Temperature | -30°C |
