TE Connectivity 68 Ω Wirewound Resistor 5 W 5 % SQMW568RJ

Bulk discount available
View bulk pricing options

Subtotal (1 pack of 5 units)*

£3.97

(exc. VAT)

£4.77

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 45 unit(s) shipping from 23 November 2026
  • Plus 60 unit(s) shipping from 27 November 2026
  • Plus 1,000 unit(s) shipping from 14 January 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
Per Pack*
5 - 45£0.794£3.97
50 - 245£0.524£2.62
250 - 495£0.436£2.18
500 - 1245£0.398£1.99
1250 +£0.358£1.79

*price indicative

Packaging Options:
RS Stock No.:
199-7753
Mfr. Part No.:
SQMW568RJ
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Product Type

Resistor

Resistance

68Ω

Resistor Type

Power

Power Rating

5W

Packaging

Box

Tolerance ±

5%

Axial/Radial

Radial

Voltage

350V

Technology

Wirewound

Series

SQM5

Automotive Standard

No

Pin Count

2

Lead Pitch Radial

5mm

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

250°C

Height

9mm

Width

13mm

Standards/Approvals

No

Length

25mm

Temperature Coefficient

±300 ppm/°C

5W SQM5 Series


TE Connectivity SQ series high power resistors featuring fine non-alkali ceramic cores embodied in ceramic cases and sealed with inorganic silica filler. This provides the SQ series with high insulation resistance, low surface temperature, excellent TCR and an entirely fireproof construction. The SQ series resistors are ideally suited to any application where efficient thermal performance is required.

Flameproof

Power rating of 5W at 70°C

Resistor marked with Value

Overload Maximum 700V

Working Voltage 350V

Ideal for small batch production, development and R&D department
