ETA 104-PR Thermal Circuit Breaker - 1-Pole, Base, 800 mA Current Rating, 25 A, 240 V ac, 48 V dc
- RS Stock No.:
- 728-8601
- Mfr. Part No.:
- 104-PR-0.8A
- Brand:
- ETA
Bulk discount available
Subtotal (1 unit)*
£13.53
(exc. VAT)
£16.24
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship from another location
- Plus 8 unit(s) shipping from 24 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 14 | £13.53 |
| 15 - 24 | £12.82 |
| 25 + | £12.39 |
*price indicative
- RS Stock No.:
- 728-8601
- Mfr. Part No.:
- 104-PR-0.8A
- Brand:
- ETA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ETA | |
| Product Type | Thermal Circuit Breaker | |
| Current Rating | 800 mA | |
| Series | 104-PR | |
| Number of Poles | 1 | |
| Width | 11 mm | |
| Mount Type | Base | |
| Terminal Type | Screw | |
| Tripping Mechanism | Thermal | |
| Reset Actuator Type | Button | |
| Tripping Characteristics | Type R | |
| Rated AC Voltage | 240 V ac | |
| Standards/Approvals | RoHS, CE | |
| Rated DC Voltage | 48 V dc | |
| Breaking Capacity | 25A | |
| Break Time | Medium | |
| Select all | ||
|---|---|---|
Brand ETA | ||
Product Type Thermal Circuit Breaker | ||
Current Rating 800 mA | ||
Series 104-PR | ||
Number of Poles 1 | ||
Width 11 mm | ||
Mount Type Base | ||
Terminal Type Screw | ||
Tripping Mechanism Thermal | ||
Reset Actuator Type Button | ||
Tripping Characteristics Type R | ||
Rated AC Voltage 240 V ac | ||
Standards/Approvals RoHS, CE | ||
Rated DC Voltage 48 V dc | ||
Breaking Capacity 25A | ||
Break Time Medium | ||
104-PR Series Thermal Circuit Breaker
Miniaturised single pole thermal circuit breaker with push-to-reset
Trip-free, snap action mechanism
Solder terminal pins for PCB mounting
Approved to CBE standard EN 60934 (IEC 60934)
Typical applications in motors, transformers, solenoids, printed circuit boards, hand-held machines and appliances, marine applications, etc.
Approvals
UL; CSA; VDE; SEV and NEMKO.
