ETA Thermal Magnetic Circuit Breaker - 2210 Single Pole DIN Rail Mount, 25A Current Rating
- RS Stock No.:
- 282-8787
- Distrelec Article No.:
- 301-66-025
- Mfr. Part No.:
- 2210-T210-K0M1-H121-25A
- Brand:
- ETA
Subtotal (1 unit)*
£44.96
(exc. VAT)
£53.95
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 104 unit(s) ready to ship
- Plus 5 unit(s) ready to ship from another location
- Plus 160 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £44.96 |
*price indicative
- RS Stock No.:
- 282-8787
- Distrelec Article No.:
- 301-66-025
- Mfr. Part No.:
- 2210-T210-K0M1-H121-25A
- Brand:
- ETA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ETA | |
Current Rating | 25A | |
Number of Poles | 1 | |
Width | 12.5mm | |
Series | 2210 | |
Reset Actuator Type | Toggle Switch | |
Mounting Style | DIN Rail Mount | |
Select all | ||
---|---|---|
Brand ETA | ||
Current Rating 25A | ||
Number of Poles 1 | ||
Width 12.5mm | ||
Series 2210 | ||
Reset Actuator Type Toggle Switch | ||
Mounting Style DIN Rail Mount | ||
- COO (Country of Origin):
- DE
For Precision Applications, 2210 Series
Overload and short circuit protecting, DIN rail mounting, time delay type thermal-magnetic single-pole CBE, suitable for process control, telecom and other professional/precision applications, etc.
Toggle operated trip-free mechanism
Auxiliary contact (NC) for remote signalling of contact breaker status
Narrow profile enables high density packaging
Compatible with Top-hat and G-profile DIN-rail
Compatible with modular DIN 43880 housings
IEC Classification S/TM
20 - 30 second tripping time
Typical life - 5000 Ops.
Auxiliary contact (NC) for remote signalling of contact breaker status
Narrow profile enables high density packaging
Compatible with Top-hat and G-profile DIN-rail
Compatible with modular DIN 43880 housings
IEC Classification S/TM
20 - 30 second tripping time
Typical life - 5000 Ops.
Approvals
UL, CSA, VDE, BV, LRoS
Thermal Magnetic Convertible
All CBEs have blade terminals and have an insulation resistance greater than 100MΩ (MegaOhms).
