ETA 3120-N 3120-N Thermal Circuit Breaker - 5-Pole, Screw, 10 A Current Rating, 10 A, 240 V ac, 50 V dc

View all Thermal Breakers
Bulk discount available

Subtotal (1 unit)*

£28.05

(exc. VAT)

£33.66

(inc. VAT)

Add to Basket
Select or type quantity
Limited stock
  • 1 left, ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£28.05
5 - 9£26.65
10 +£24.50

*price indicative

RS Stock No.:
210-2111
Mfr. Part No.:
3120-N554-P7T1-W19DG4-10A
Brand:
ETA
Find similar products by selecting one or more attributes.
Select all

Brand

ETA

Product Type

Thermal Circuit Breaker

Current Rating

10 A

Range

3120-N

Series

3120-N

Number of Poles

5

Width

28 mm

Mount Type

Screw

Terminal Type

Blade

Tripping Mechanism

Thermal

Reset Actuator Type

Rocker

Standards/Approvals

RoHS, REACH, CCC, VDE, IEC, CSA, EAC

Rated AC Voltage

240 V ac

Height

52.4mm

Depth

42.6mm

Breaking Capacity

10A

Rated DC Voltage

50 V dc

COO (Country of Origin):
TN
The ETA 3120-N 5-pole thermal rocker actuated circuit breaker/switch combination unites overcurrent protection and the function of an ON/OFF switch within a single component. It has blade terminals. The trip element is a thermal bimetal. After tripping, it can reliably, easily and quickly be reset. The positively trip-free mechanism ensures reliable disconnection of the circuit even with the actuator blocked. It is ideally suited for overload protection of motors, pumps, transformers and cables.

Mounting type: Snap-in, cut-out 44.5mm x 22mm

Current rating: 10A

Extendable functionality through appliance inlet module

Water splash protection

Reduced mounting and wiring time

Space-saving design

Reduced disposition and storage costs

Increased overall reliability
