Schneider Electric TeSys GV3 Thermal Circuit Breaker - 3-Pole, Direct, 18A Current Rating, 100 kA, 690V ac
- RS Stock No.:
- 272-892
- Mfr. Part No.:
- GV3P18
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£158.33
(exc. VAT)
£190.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 2 unit(s) ready to ship from another location
- Plus 6 unit(s) shipping from 28 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £158.33 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 272-892
- Mfr. Part No.:
- GV3P18
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | Thermal Circuit Breaker | |
| Current Rating | 18A | |
| Series | GV3 | |
| Range | TeSys | |
| Number of Poles | 3 | |
| Width | 55mm | |
| Mount Type | Direct | |
| Terminal Type | Screw | |
| Tripping Mechanism | Thermal Magnetic | |
| Reset Actuator Type | Toggle Switch | |
| Standards/Approvals | RoHS, CE | |
| Depth | 136mm | |
| Height | 160mm | |
| Rated AC Voltage | 690V ac | |
| Better World Product | Yes | |
| Break Time | Medium | |
| Breaking Capacity | 100kA | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type Thermal Circuit Breaker | ||
Current Rating 18A | ||
Series GV3 | ||
Range TeSys | ||
Number of Poles 3 | ||
Width 55mm | ||
Mount Type Direct | ||
Terminal Type Screw | ||
Tripping Mechanism Thermal Magnetic | ||
Reset Actuator Type Toggle Switch | ||
Standards/Approvals RoHS, CE | ||
Depth 136mm | ||
Height 160mm | ||
Rated AC Voltage 690V ac | ||
Better World Product Yes | ||
Break Time Medium | ||
Breaking Capacity 100kA | ||
Schneider Electric GV3 Series Thermal Circuit Breaker, 18A Current, 690V AC Rated AC Voltage - GV3P18
This thermal circuit-breaker provides thermal-magnetic motor protection for three-phase AC networks up to 690 V. Designed for use in control panels and DIN-rail systems, it interrupts fault currents and protects motors within its adjustable thermal range while allowing manual reset via a toggle-style actuator.
Features & Benefits
• 100 kA breaking capacity delivers high short-circuit interruption performance
• 12 to 18A thermal adjustment protects motors across load variations
• 18A conventional thermal current for continuous-duty applications
• 252A magnetic trip limits damage from high short-duration faults
• Screw terminals with EverLink compatibility ensure secure conductor connection
• 12 to 18A thermal adjustment protects motors across load variations
• 18A conventional thermal current for continuous-duty applications
• 252A magnetic trip limits damage from high short-duration faults
• Screw terminals with EverLink compatibility ensure secure conductor connection
Applications
• Suitable for motor protection in industrial control panels
• Ideal for starters handling 7.5 kW to 15 kW motors depending on voltage
• used with contactor assemblies in automation installations
• Can be used for retrofit protection on 35mm DIN rails
• Ideal for starters handling 7.5 kW to 15 kW motors depending on voltage
• used with contactor assemblies in automation installations
• Can be used for retrofit protection on 35mm DIN rails
What mounting options are available for installation?
It can be clipped onto 35mm symmetrical DIN rail or fastened to a panel using three M4 screws, allowing flexible mounting in cabinets or on equipment frames.
How does it perform under elevated ambient temperatures?
Thermal trip settings cover the 12 to 18A range to compensate for varying ambient conditions and maintain motor protection over the specified -20 to 60 °C operating range.
What mechanical and electrical life can be expected?
The device is rated for 50,000 mechanical cycles and 50,000 electrical cycles for AC-3 use at 415 V, supporting frequent switching in industrial environments.
Are there protection degrees and environmental tolerances to consider?
The enclosure meets IK09 impact resistance and provides IP20 protection
it also withstands storage from -40 to 80 °C and complies with the specified vibration and shock limits.
Standards
IEC 947 and UL 508 type E certification
