KYOCERA AVX 47μF Electrolytic Tantalum Capacitor 6.3V dc, F98 Series
- RS Stock No.:
- 136-2603
- Mfr. Part No.:
- F980J476MMA
- Brand:
- KYOCERA AVX
Bulk discount available
Subtotal (1 bag of 25 units)*
£13.325
(exc. VAT)
£16.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
---|---|---|
25 - 100 | £0.533 | £13.33 |
125 - 475 | £0.412 | £10.30 |
500 - 1225 | £0.401 | £10.03 |
1250 + | £0.39 | £9.75 |
*price indicative
- RS Stock No.:
- 136-2603
- Mfr. Part No.:
- F980J476MMA
- Brand:
- KYOCERA AVX
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KYOCERA AVX | |
Technology | Electrolytic | |
Capacitance | 47µF | |
Voltage | 6.3V dc | |
Mounting Type | Surface Mount | |
Package/Case | 0603 (1608M) | |
Equivalent Series Resistance | 10Ω | |
Length | 1.6mm | |
Height | 0.8mm | |
Dimensions | 1.6 x 0.85 x 0.8mm | |
Series | F98 | |
Maximum Operating Temperature | +125°C | |
Electrolyte Type | Solid | |
Leakage Current | 29.6 μA | |
Polarised | Polar | |
Terminal Type | SMD | |
Dissipation Factor | 45% | |
Dielectric Material Family | Tantalum | |
Minimum Operating Temperature | -55°C | |
Select all | ||
---|---|---|
Brand KYOCERA AVX | ||
Technology Electrolytic | ||
Capacitance 47µF | ||
Voltage 6.3V dc | ||
Mounting Type Surface Mount | ||
Package/Case 0603 (1608M) | ||
Equivalent Series Resistance 10Ω | ||
Length 1.6mm | ||
Height 0.8mm | ||
Dimensions 1.6 x 0.85 x 0.8mm | ||
Series F98 | ||
Maximum Operating Temperature +125°C | ||
Electrolyte Type Solid | ||
Leakage Current 29.6 μA | ||
Polarised Polar | ||
Terminal Type SMD | ||
Dissipation Factor 45% | ||
Dielectric Material Family Tantalum | ||
Minimum Operating Temperature -55°C | ||
AVX F98 Series Tantalum Capacitor (Resin Moulded Chip)
AVX F98 series resin molded chip high cv undertab features an SMD face down design with a small and low profile. These capacitors are compact with SMD resin-molded chips with high capacitance between 1 μF and 200 μF, rated voltages between 4 V and 25 V.The Capacitors are RoHS compliant to directive 2002/95/EC and offer high CV capabilities with the undertab design, and have small case sizes such as 0402, 0603, and 0805.
Applications
Mobile Phones
Smartphones
Hearing Aids
Wireless module
Smartphones
Hearing Aids
Wireless module
