Bulk discount available
Subtotal (1 unit)*
£9.52
(exc. VAT)
£11.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 26 unit(s) ready to ship
- Plus 3 unit(s) shipping from 30 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £9.52 |
| 25 - 99 | £7.86 |
| 100 - 249 | £6.59 |
| 250 - 499 | £5.77 |
| 500 + | £5.48 |
*price indicative
- RS Stock No.:
- 703-8706
- Mfr. Part No.:
- 200NHG1B
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Current Rating | 200A | |
| Fuse Size | NH1 | |
| Voltage Rating | 500V ac | |
| Fuse Standard | DIN 43620-1, DIN 43620-3, IEC 60269, VDE 0636 | |
| Application Category | gG - gL | |
| Tag Width | 6mm | |
| High Rupture Capacity | Yes | |
| Overall Length | 135mm | |
| Body Length | 75mm | |
| Body Width | 40mm | |
| Body Height | 63mm | |
| Fuse Dimensions | 135 x 63 x 40mm | |
| Series | NH | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Current Rating 200A | ||
Fuse Size NH1 | ||
Voltage Rating 500V ac | ||
Fuse Standard DIN 43620-1, DIN 43620-3, IEC 60269, VDE 0636 | ||
Application Category gG - gL | ||
Tag Width 6mm | ||
High Rupture Capacity Yes | ||
Overall Length 135mm | ||
Body Length 75mm | ||
Body Width 40mm | ||
Body Height 63mm | ||
Fuse Dimensions 135 x 63 x 40mm | ||
Series NH | ||
- COO (Country of Origin):
- IN
Eaton Series NH Centred Tag Fuse, 200A Current Rating, 500V AC Voltage Rating - 200NHG1B
This centred tag fuse is an essential component for electrical protection in industrial settings. With a current rating of 200A and a voltage rating of 500V AC, it is designed to ensure high rupture capacity in varied applications. The fuse dimensions measure 135mm in length and 63mm in height, making it compatible with standard NH fuse gear.
Features & Benefits
• Designed for gG and gL application categories to offer versatility
• Complies with DIN 43620-1, IEC 60269 and VDE 0636 standards
• High rupture capacity ensures enhanced safety during overloads
• Reliable dual indicator system aids in monitoring performance
• Low temperature rise promotes more efficient operation
• Complies with DIN 43620-1, IEC 60269 and VDE 0636 standards
• High rupture capacity ensures enhanced safety during overloads
• Reliable dual indicator system aids in monitoring performance
• Low temperature rise promotes more efficient operation
Applications
• Used with NH fuse bases in industrial circuits
• Suitable for electrical requiring high current protection
• Employed in automation and mechanical sectors for safety measures
• Ideal for sectors adhering to stringent electrical standards
• Suitable for electrical requiring high current protection
• Employed in automation and mechanical sectors for safety measures
• Ideal for sectors adhering to stringent electrical standards
What is the breaking capacity of this fuse?
The breaking capacity of the fuse is rated at 120 kA AC., ensuring it can handle significant fault currents without failing.
How does the dual indicator system function?
The dual indicator system provides clear visual signals for both operational safety and maintenance needs, allowing for timely interventions in case of overloads.
Is this fuse suitable for low-temperature environments?
Yes, its construction features a low temperature rise, making it appropriate for use in environments that may experience colder conditions.
What standards do I need to consider when using this fuse?
It complies with international standards such as DIN 43620-1 and IEC 60269, ensuring compatibility with a wide range of systems and regulations.
Note
Eaton formerly known as Bussmann
