TDK-Lambda Switching Power Supply, ZWQ80-5225/A, 5 V dc, ±12 V dc, 2 A, 7 A, 8 A, 80W, Quad Output, 120 → 330 V
- RS Stock No.:
- 635-2262
- Mfr. Part No.:
- ZWQ80-5225/A
- Brand:
- TDK-Lambda
7 In stock for delivery within 5 working days
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£153.73
(exc. VAT)
£184.48
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £153.73 |
| 5 - 9 | £149.12 |
| 10 - 24 | £144.51 |
| 25 - 49 | £139.90 |
| 50 + | £135.29 |
- RS Stock No.:
- 635-2262
- Mfr. Part No.:
- ZWQ80-5225/A
- Brand:
- TDK-Lambda
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
ZWQ Series, 4 Outputs, 80 W
Active filter supports harmonic current regulations
Wide-input voltage range: 85 to 265 V ac
Wide-input voltage range: 85 to 265 V ac
Standards
UL1950, CSA950, EN60950
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 5 V dc, ±12 V dc |
| Output Current | 2 A, 7 A, 8 A |
| Power Rating | 80W |
| Number of Outputs | 4 |
| Input Voltage | 120 → 330 V dc, 85 → 265 V ac |
| Mounting Type | Chassis Mount |
| Package Type | Enclosed |
| Length | 210mm |
| Width | 93.5mm |
| Depth | 35mm |
| Efficiency | 70% |
| Minimum Temperature | -10°C |
| Maximum Temperature | +60°C |
| Weight | 550g |
