TRACOPOWER Power Supply, TPI 180-136A-M, 36V dc, 7.5A, 180W, 1 Output, 85 → 264V ac Input Voltage
- RS Stock No.:
- 249-9814
- Distrelec Article No.:
- 302-64-438
- Mfr. Part No.:
- TPI 180-136A-M
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£88.34
(exc. VAT)
£106.01
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £88.34 |
| 5 - 9 | £85.70 |
| 10 - 24 | £83.04 |
| 25 - 49 | £79.51 |
| 50 + | £75.97 |
*price indicative
- RS Stock No.:
- 249-9814
- Distrelec Article No.:
- 302-64-438
- Mfr. Part No.:
- TPI 180-136A-M
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 36V dc | |
| Output Current | 7.5A | |
| Power Rating | 180W | |
| Number of Outputs | 1 | |
| Input Voltage | 85 → 264V ac | |
| Mounting Type | Chassis Mount | |
| Package Type | Open Frame | |
| Length | 76.2mm | |
| Width | 50.8mm | |
| Medical Approved | Yes | |
| Embedded | No | |
| Depth | 31.6mm | |
| Series | TPI 180A-M | |
| Efficiency | 93% | |
| Weight | 165g | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 36V dc | ||
Output Current 7.5A | ||
Power Rating 180W | ||
Number of Outputs 1 | ||
Input Voltage 85 → 264V ac | ||
Mounting Type Chassis Mount | ||
Package Type Open Frame | ||
Length 76.2mm | ||
Width 50.8mm | ||
Medical Approved Yes | ||
Embedded No | ||
Depth 31.6mm | ||
Series TPI 180A-M | ||
Efficiency 93% | ||
Weight 165g | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
TRACOPOWER TPI 180A-M Series Power Supply, 180W Power Rating, 93% Efficiency - TPI 180-136A-M
This open frame AC/DC power supply is designed for various industrial and medical applications. With compact dimensions of 76.2mm x 50.8mm and a depth of 31.6mm, it provides a consistent output of 36V DC with a maximum current of 7.5A. It operates effectively across a wide input voltage range and complies with rigorous safety standards.
Features & Benefits
• High efficiency results in lower energy consumption
• Chassis mount design facilitates installation
• Operates in a broad temperature range for flexible applications
• Medical approval ensures safety for health-related uses
• Reinforced double I/O isolation enhances reliability
• Chassis mount design facilitates installation
• Operates in a broad temperature range for flexible applications
• Medical approval ensures safety for health-related uses
• Reinforced double I/O isolation enhances reliability
Applications
• Compatible with automation systems
• Suitable for powering medical devices
• Used in electronic testing equipment
• Supports telecommunications equipment
• Suitable for powering medical devices
• Used in electronic testing equipment
• Supports telecommunications equipment
Can it operate in extreme temperatures?
Yes, it functions from -40°C to +85°C.
Will it deliver peak power?
It can provide peak power of 220W for 5 seconds.
Does it require any special cooling?
It operates well with natural convection, although forced air cooling can be advantageous.
