Infineon Switching Diode, Fast Switching, 12 A, 3-Pin 1200 V TO-220 IDP12E120XKSA1

View all Switching Diodes
Bulk discount available

Subtotal (1 pack of 2 units)*

£3.32

(exc. VAT)

£3.98

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 298 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 - 18£1.66£3.32
20 - 48£1.475£2.95
50 - 98£1.395£2.79
100 - 198£1.295£2.59
200 +£1.195£2.39

*price indicative

Packaging Options:
RS Stock No.:
258-0973
Mfr. Part No.:
IDP12E120XKSA1
Brand:
Infineon
Find similar products by selecting one or more attributes.
Select all

Brand

Infineon

Diode Configuration

Fast Switching

Product Type

Switching Diode

Maximum Forward Current If

12A

Mount Type

Surface

Sub Type

Diode & Rectifiers

Package Type

TO-220

Pin Count

3

Maximum Forward Voltage Vf

1.65V

Minimum Operating Temperature

-55°C

Peak Non-Repetitive Forward Surge Current Ifsm

63A

Maximum Power Dissipation Pd

96W

Peak Reverse Recovery Time trr

150ns

Maximum Peak Reverse Repetitive Voltage Vrrm

1200V

Maximum Operating Temperature

150°C

Series

IDP12E120

Standards/Approvals

IEC61249-2-21, JEDEC, RoHS

Automotive Standard

No

The Infineon emitter controlled silicon power diode in a TO-220 real 2-leg package displays excellent softness and VF behaviour and is qualified with a Tj(max) of 150°C. The diodes are also available halogen-free according to IEC61249-2-21.

Cooler packages and higher efficiency

Excellent EMI behaviour

Excellent trade-off between cost and performance

Low conduction losses
