Panasonic 10Ω, 0805 (2012M) Thick Film SMD Resistor ±5% 0.25W - ERJT06J10RV
- RS Stock No.:
- 922-8816
- Mfr. Part No.:
- ERJT06J100V
- Brand:
- Panasonic
Available to back order for despatch 01/11/2024
Added
Price Each (On a Reel of 5000)
£0.015
(exc. VAT)
£0.018
(inc. VAT)
| Units | Per unit | Per Reel* |
| 5000 - 5000 | £0.015 | £75.00 |
| 10000 - 15000 | £0.014 | £70.00 |
| 20000 - 35000 | £0.014 | £70.00 |
| 40000 + | £0.013 | £65.00 |
| *price indicative | ||
- RS Stock No.:
- 922-8816
- Mfr. Part No.:
- ERJT06J100V
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
0805 Format Anti-Pulse Resistors, ERJT06 Series - 5%
Panasonic ERJ T06 anti-pulse thick film chip resistors are constructed from three layers of electrodes and a metal glaze thick film resistive element. The optimised trimming specifications of these chip resistors ensure high pulse characteristics. Highly reliable and suitable for flow and reflow soldering, these chip resistors are AEC-Q200 qualified.
Features and Benefits:
Anti-pulse characteristics
0.25 W high-power rating
High reliability
Both reflow and flow soldering can be used
0.25 W high-power rating
High reliability
Both reflow and flow soldering can be used
Applications
These chip resistors are AEC-Q200 qualified and are suitable for use in automotive applications.
Standards
IEC 60115-8, JIS C 5201-8, EIAJ RC-2134B
Specifications
Attribute | Value |
|---|---|
| Resistance | 10Ω |
| Technology | Thick Film |
| Package/Case | 0805 (2012M) |
| Tolerance | ±5% |
| Power Rating | 0.25W |
| Temperature Coefficient | ±300ppm/°C |
| Series | ERJT06 |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +155°C |
- RS Stock No.:
- 922-8816
- Mfr. Part No.:
- ERJT06J100V
- Brand:
- Panasonic
