Arcol Ohmite HVC 0.1 GΩ, 0603 Thick Film Surface Mount Fixed Resistor 1 % 0.1 W - HVC0603T1006FET
- RS Stock No.:
- 263-4257
- Mfr. Part No.:
- HVC0603T1006FET
- Brand:
- Arcol Ohmite
Subtotal (1 reel of 500 units)*
£375.00
(exc. VAT)
£450.00
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Reel* |
|---|---|---|
| 500 + | £0.75 | £375.00 |
*price indicative
- RS Stock No.:
- 263-4257
- Mfr. Part No.:
- HVC0603T1006FET
- Brand:
- Arcol Ohmite
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol Ohmite | |
| Product Type | Surface Mount Fixed Resistor | |
| Resistance | 0.1GΩ | |
| Technology | Thick Film | |
| Package/Case | 0603 | |
| Packaging | Tape & Reel | |
| Tolerance | 1 % | |
| Voltage | 150V | |
| Power Rating | 0.1W | |
| Automotive Standard | No | |
| Series | HVC | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 55°C | |
| Termination Style | Solder | |
| Length | 1.5mm | |
| Standards/Approvals | RoHS | |
| Height | 0.4mm | |
| Select all | ||
|---|---|---|
Brand Arcol Ohmite | ||
Product Type Surface Mount Fixed Resistor | ||
Resistance 0.1GΩ | ||
Technology Thick Film | ||
Package/Case 0603 | ||
Packaging Tape & Reel | ||
Tolerance 1 % | ||
Voltage 150V | ||
Power Rating 0.1W | ||
Automotive Standard No | ||
Series HVC | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 55°C | ||
Termination Style Solder | ||
Length 1.5mm | ||
Standards/Approvals RoHS | ||
Height 0.4mm | ||
- COO (Country of Origin):
- DE
The Arcol Ohmite HVC series wraparound chip resistor is available in thick film construction technology. It is mostly suitable for high vacuum applications and it also offers an high working voltage up to 6000 volts.
Low temperature and voltage dependency
Contact areas are nickel barrier or matte tin
Wraparound terminals
