TDK, VLCF, 5020 Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±30% Shielded 3.25A Idc
- RS Stock No.:
- 916-4276
- Mfr. Part No.:
- VLCF5020T-2R2N2R6-3
- Brand:
- TDK
Save 34% when you buy 1000 units
Subtotal (1 pack of 10 units)*
£4.98
(exc. VAT)
£5.98
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 450 unit(s) ready to ship
- Plus 2,000 unit(s) shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
10 - 90 | £0.498 | £4.98 |
100 - 240 | £0.398 | £3.98 |
250 - 490 | £0.374 | £3.74 |
500 - 990 | £0.349 | £3.49 |
1000 + | £0.324 | £3.24 |
*price indicative
- RS Stock No.:
- 916-4276
- Mfr. Part No.:
- VLCF5020T-2R2N2R6-3
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TDK | |
Inductance | 2.2 μH | |
Maximum DC Current | 3.25A | |
Package/Case | 5020 | |
Length | 5mm | |
Depth | 5mm | |
Height | 2mm | |
Dimensions | 5 x 5 x 2mm | |
Shielded | Yes | |
Tolerance | ±30% | |
Maximum DC Resistance | 43mΩ | |
Series | VLCF | |
Core Material | Ferrite | |
Maximum Operating Temperature | +105°C | |
Minimum Operating Temperature | -40°C | |
Inductor Construction | Shielded | |
Select all | ||
---|---|---|
Brand TDK | ||
Inductance 2.2 μH | ||
Maximum DC Current 3.25A | ||
Package/Case 5020 | ||
Length 5mm | ||
Depth 5mm | ||
Height 2mm | ||
Dimensions 5 x 5 x 2mm | ||
Shielded Yes | ||
Tolerance ±30% | ||
Maximum DC Resistance 43mΩ | ||
Series VLCF | ||
Core Material Ferrite | ||
Maximum Operating Temperature +105°C | ||
Minimum Operating Temperature -40°C | ||
Inductor Construction Shielded | ||
VLCF5020 Series Magnetically Shielded Wire Wound Chokes
Professional series of TDK surface mount power inductor from the VLCF range which offers magnetic shield type wound inductor for power circuits.
Features and Benefits:
High magnetic shield construction
Generic use portable DC to DC converter line
Test frequency = 100 kHz
Generic use portable DC to DC converter line
Test frequency = 100 kHz
Applications:
Power source inductor for mobile devices such as HDDs, DVCs, and DSCs. LCD displays and other DC to DC converters.
