Bourns, SRP1038A, 1038 Shielded Wirewound Surface Mount Inductor with a Carbonyl Powder Core, 2.2 μH ±20 % 12 A Idc Q:20
- RS Stock No.:
- 819-3321
- Distrelec Article No.:
- 304-36-354
- Mfr. Part No.:
- SRP1038A-2R2M
- Brand:
- Bourns
Bulk discount available
Subtotal (1 bag of 5 units)*
£4.28
(exc. VAT)
£5.135
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 25 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 5 - 45 | £0.856 | £4.28 |
| 50 - 245 | £0.63 | £3.15 |
| 250 - 495 | £0.614 | £3.07 |
| 500 - 1245 | £0.598 | £2.99 |
| 1250 + | £0.584 | £2.92 |
*price indicative
- RS Stock No.:
- 819-3321
- Distrelec Article No.:
- 304-36-354
- Mfr. Part No.:
- SRP1038A-2R2M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 2.2μH | |
| Product Type | Wirewound Surface Mount Inductor | |
| Maximum DC Current | 12A | |
| Package/Case | 1038 | |
| Length | 11mm | |
| Packaging | Reel | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Pin Count | 2 | |
| Maximum DC Resistance | 7mΩ | |
| Minimum Operating Temperature | -40°C | |
| Series | SRP1038A | |
| Inductance Tolerance | ±20 % | |
| Maximum Operating Temperature | 150°C | |
| Height | 3.8mm | |
| Standards/Approvals | RoHS | |
| Termination Style | Solder | |
| Depth | 10mm | |
| Core Material | Carbonyl Powder | |
| Maximum Self Resonant Frequency | 25MHz | |
| Minimum Quality Factor | 20 | |
| Moulded | Yes | |
| Inductor Construction | Wirewound | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 2.2μH | ||
Product Type Wirewound Surface Mount Inductor | ||
Maximum DC Current 12A | ||
Package/Case 1038 | ||
Length 11mm | ||
Packaging Reel | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Pin Count 2 | ||
Maximum DC Resistance 7mΩ | ||
Minimum Operating Temperature -40°C | ||
Series SRP1038A | ||
Inductance Tolerance ±20 % | ||
Maximum Operating Temperature 150°C | ||
Height 3.8mm | ||
Standards/Approvals RoHS | ||
Termination Style Solder | ||
Depth 10mm | ||
Core Material Carbonyl Powder | ||
Maximum Self Resonant Frequency 25MHz | ||
Minimum Quality Factor 20 | ||
Moulded Yes | ||
Inductor Construction Wirewound | ||
SRP1038A Series Magnetically Shielded Power Inductors
SRP1038A Series inductors have a shielded construction
Carbonyl powder core
High saturation current
Inductance range is 0.22 to 47 μH
Applications include Automotive systems (Driver assistant, Information, Entertainment and Lighting), DC/DC converters and Power supplies
