TDK, B82462-A4 Wirewound Surface Mount Inductor with a Ferrite Core, 33 μH ±20/±10 % 1.8 A Idc
- RS Stock No.:
- 496-0451
- Mfr. Part No.:
- B82464A4333K000
- Brand:
- TDK
Subtotal (1 unit)*
£0.83
(exc. VAT)
£1.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 91 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £0.83 |
*price indicative
- RS Stock No.:
- 496-0451
- Mfr. Part No.:
- B82464A4333K000
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK | |
| Inductance | 33μH | |
| Product Type | Wirewound Surface Mount Inductor | |
| Maximum DC Current | 1.8A | |
| Length | 10.4mm | |
| Automotive Standard | AEC-Q200 | |
| Maximum DC Resistance | 100mΩ | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 150°C | |
| Series | B82462-A4 | |
| Inductance Tolerance | ±20/±10 % | |
| Standards/Approvals | RoHS | |
| Termination Style | Winding Welded To Terminal | |
| Depth | 10.4mm | |
| Core Material | Ferrite | |
| Height | 4.8mm | |
| Maximum Self Resonant Frequency | 13MHz | |
| Inductor Construction | Wirewound | |
| Select all | ||
|---|---|---|
Brand TDK | ||
Inductance 33μH | ||
Product Type Wirewound Surface Mount Inductor | ||
Maximum DC Current 1.8A | ||
Length 10.4mm | ||
Automotive Standard AEC-Q200 | ||
Maximum DC Resistance 100mΩ | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 150°C | ||
Series B82462-A4 | ||
Inductance Tolerance ±20/±10 % | ||
Standards/Approvals RoHS | ||
Termination Style Winding Welded To Terminal | ||
Depth 10.4mm | ||
Core Material Ferrite | ||
Height 4.8mm | ||
Maximum Self Resonant Frequency 13MHz | ||
Inductor Construction Wirewound | ||
B82464-A4 Series Wire Wound Chokes
SMT size 10 x 10mm
Ferrite core construction
Leadfree tinned terminals
Wide operating temperature -55°C → +125°C
Very high rated current
Low DC resistance
Applications in filtering of power supplies
Epcos Non Standard SMT Inductors (Chokes)
