Panasonic, ETQP5M Shielded Power Choke Coil with a Metal Composite Core, 1.9 μH ±20 % 29.8 A Idc

View all Surface Mount Inductors

Subtotal (1 reel of 500 units)*

£273.00

(exc. VAT)

£327.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 500 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
500 +£0.546£273.00

*price indicative

RS Stock No.:
240-4040
Mfr. Part No.:
ETQP5M2R0YSC
Brand:
Panasonic
Find similar products by selecting one or more attributes.
Select all

Brand

Panasonic

Product Type

Power Choke Coil

Inductance

1.9μH

Maximum DC Current

29.8A

Length

10.9mm

Packaging

Tape & Reel

Automotive Standard

AEC-Q200

Shielding

Yes

Pin Count

2

Maximum DC Resistance

4.9mΩ

Minimum Operating Temperature

-40°C

Inductance Tolerance

±20 %

Series

ETQP5M

Maximum Operating Temperature

150°C

Termination Style

Surface Mount

Standards/Approvals

RoHS

Core Material

Metal Composite

Height

5mm

Depth

5mm

Maximum Self Resonant Frequency

100kHz

Inductor Construction

Wirewound

Moulded

Yes

The Panasonic Power Inductor metal composite SMD power choke coils (PCC) are specially designed for automotive use and feature superior robustness and high reliability. Performance attributes include non-saturation behaviour, low losses and stability over a wide temperature range.

High heat resistance operation up to 150 degree celcius including self-heating

High-reliability with high vibration resistance as result of newly developed integral construction under severe reliability conditions of automotive and other strenuous applications

High bias current with excellent inductance stability using ferrous alloy magnetic material

Excellent inductance stability over broad temp range

Low audible buzz noise

High efficiency with low DC resistance of winding and low eddy-current loss of the core

Shielded construction
